Description

Challenger MT945E, MT955E, MT965E, MT975E Tractor Repair Workshop Manual

Manual for: AGCO Challenger MT900E Series Tractor
Format: PDF
Book Number: 79036231G & 575285D1C
English
Issued June 2019

Challenger MT945E, MT955E, MT965E, MT975E Tractor Workshop Manual : 2920 Pages
Challenger MT945E, MT955E, MT965E, MT975E Tractor Repair Schedule Manual : 182 Pages

MT900E Series Manual TABLE OF CONTENTS

• General
• Engine, Fuel and exhaust
• Axles
• Frame and suspension
• Steering System
• Drivetrain System
• Brake System
• Compressed Air System
• Hydraulic System
• Electrical System
• Cab
• Air Conditioning and Heating
• Chassis
• Wheels
• Implement drive System
• Implement Lift System
• Attachements
• Diagrams
• Specials Tools

MT945E, MT955E, MT965E, MT975E Manual Extract- Axle maintenance

Procedure
1. Remove the axle lubrication filter (1) from the filter head (2).
2. Put the new axle lubrication filter into the filter head and tighten.
3. Change the axle lubrication filter at the same time as the transmission fluid.
4. Change the transmission fluid at the initial 250 hours and every 1,000 hours after.

Remove the cassette seal

Procedure
1. Have the correct container available for all fluid removal.
2. Remove the wheels and the hubs to get access to the cassette seal.
NOTE:
It is not necessary to remove the axle from the machine to replace the cassette seal.
3. Remove the drain plugs from the bottom side of the final drive to drain the final drive and the service brakes.
4. Drain approximately 18.9 to 22.7 L (5 to 6 gallons). Install the drain plugs.
5. Use a seal removal tool to remove the cassette seal (1 ).
6. Make sure not to make any marks on the final drive (2) or the bushing (3).
