BT PE, PL, HT Series Trucks Operating - Maintenance - Parts Manual 309829-000
BT PE, PL, HT Series Trucks Operating - Maintenance - Parts Manual 309829-000 - Image 2
BT PE, PL, HT Series Trucks Operating - Maintenance - Parts Manual 309829-000 - Image 3
BT PE, PL, HT Series Trucks Operating - Maintenance - Parts Manual 309829-000 - Image 4
BT PE, PL, HT Series Trucks Operating - Maintenance - Parts Manual 309829-000 - Image 5

BT PE, PL, HT Series Trucks Operating – Maintenance – Parts Manual 309829-000

$30.00

  • Type Of Manual: Operating – Maintenance – Parts Manual
  • Manual ID: 309829-000
  • : Parts Manual PDF
  • Number of Pages: 88
  • Size: 3.1MB
  • Format: PDF
Category:

Product details

  • Model List:

    • PE-45, PE-45R, PE-45C, PE-60, PE-60R, PL-45, HT-45, HT-60
  • 1. Front Cover
  • 2. Warranty
  • 3. New Owners
  • 4. Contents
  • 5. Specifications for Trucks
  • 6. Operating Rules and Instructions
  • 7. Maintenance Instructions
  • 8. Service and Disassembly Instructions
  • 9. Parts Ordering Instructions
  • 10. Parts List and Service Reference Index
  • 10.1. Shielding
  • 10.2. Pe 40C Frame Components
  • 10.3. PE/PL/HT 45 45C Carrier Frame
  • 10.4. PE/PL/HT 60 Carrier Frame
  • 10.5. PE45/C/R HT45 Lift Frame Assembly
  • 10.6. PE/HT 60 Lift Frame Assembly
  • 10.7. PL45/PL45R Platform Assembly
  • 10.8. 1 Spur Gear Transmission
  • 10.9. Volt PE Drive Motor for P-22228
  • 10.10. PE Drive Motor for P-20845
  • 10.11. PE Drive Motor for D-20513
  • 10.12. PE Drive Motor for P-20843
  • 10.13. HT 45 60 141 Transmission
  • 10.14. HT 45 60 24 Volt, Drive Motor for P-25901
  • 10.15. PE 45C Control Handle Assembly
  • 10.16. PE/HT 45 60 Control Handle Assembly
  • 10.17. PE/PL Electrical Schematic
  • 10.18. PE 45 60 Control Wiring
  • 10.19. PE 45R 60R Control Wiring
  • 10.20. Power Wiring Assembly
  • 10.21. HT 45 60 Electrical Schematic
  • 10.22. HT 45 60 Control Wiring
  • 10.23. HT 45 60 Power Wiring Diagram
  • 10.24. Electrical Control Panel/3rd Speed Panel
  • 10.25. Square D Forward/Reverse and 2nd/3rd Speed Contactors
  • 10.26. Pe 45C 3rd Speed Foot Switch Assembly
  • 10.27. PE 45C Control Wiring
  • 10.28. Dynamic Brake
  • 10.29. Control Switch Assembly for Resistor
  • 10.30. Control Switch Assembly for SCR
  • 10.31. Model 50 SCR, 24 Volt, Electrical Schematic
  • 10.32. Model 50 SCR Control Wiring
  • 10.33. Model 50 SCR Power Wiring
  • 10.34. Model 50 SCR Contactor Panel
  • 10.35. Model 50 SCR Contactor Panel Wiring Diagram
  • 10.36. Model 50 SCR Panel
  • 10.37. Model 50 SCR Panel Wiring Diagram
  • 10.38. Model 50 SCR Contactor – Forward/Reverse 1A
  • 10.39. Pump Contactor Panel Assembly
  • 10.40. Model EV-1 SCR Electrical Schematic
  • 10.41. Model EV-1 Control Wiring
  • 10.42. Model EV-1 Power Wiring
  • 10.43. Model EV-1 SCR Control Panel
  • 10.44. Model EV-1 Contactor Panel
  • 10.45. HT EV-1 Pump Contactor Panel
  • 10.46. EV-1 Forward/Reverse Contactor
  • 10.47. EV-1 1A, Contactor
  • 10.48. Hydraulic Diagram
  • 10.49. PE/HT Hydraulic Pump Motor Assembly
  • 10.50. PE/HT Hydraulic Pump Motor
  • 10.51. Lift Cylinder
  • 10.52. Pallet Entry Pollers
  • 10.53. PE/HT 45 60 Rider Platform
  • 10.54. PE/HT Options
  • 11. Service Guide
  • 12. Back Cover
