  • Type Of Manual: Operator Manual
  • Manual ID: 164181-040
  • : Operator Manual PDF
  • Number of Pages: 86
  • Size: 4.0MB
  • Format: PDF
Category:

Product details

  • Model List:

    • BT RR B1-8 AC-ACi, B1C-8C AC-ACi, BT RR E1-8 AC-ACi, E1C-8C AC-ACi, BT RR N1-3 AC-ACi, N1C-3C AC-ACi
  • 1. Return To HomePage
  • 2. BT RR B1-8 AC/ACi, B1C-8C AC/ACi BT RR E1-8 AC/ACi, E1C-8C AC/ACi BT RR N1-3 AC/ACi, N1C-3C AC/ACi
  • 2.1. Valid from serial number 301518AA-
  • 2.2. Order number 164181-040
  • 2.2.1. Issued 2000-06-26 ITS
  • 3. Safety regulations
  • 3.1. Warning symbols
  • 3.1.1. Warning levels
  • 3.1.2. Prohibitory symbols
  • 3.1.3. Ordinance symbols
  • 3.2. General safety regulations
  • 3.2.1. Operating the truck
  • 3.2.2. Operators responsibility
  • 3.2.3. Working area
  • 3.2.4. Driving and conduct while driving
  • 3.2.5. Handling loads
  • 3.2.6. Parking the truck
  • 3.2.7. Handling the battery
  • 3.2.8. Maintenance and repair
  • 4. Warning and information plates and symbols
  • 4.1. Modification plate
  • 4.2. Identification plate, truck
  • 4.3. Capacity plate
  • 4.4. Serial number
  • 4.5. Hydraulic oil filling
  • 4.6. Cab tilt lock
  • 4.7. Parking brake and travel direction selector (accessories)
  • 4.8. Lifting points
  • 4.9. Hydraulic controls lift/lowering, mast in/out, fork tilt, sideshift and additional hydraulic …
  • 4.10. Do not walk under elevated load
  • 4.11. Maximum height for rated capacity
  • 4.12. Identification plate, mast
  • 5. Presentation to BTs reach trucks
  • 5.1. Application areas for BTs reach trucks
  • 5.2. Prohibited applications for BTs reach trucks
  • 5.3. Truck data
  • 5.3.1. Truck type
  • 5.3.2. B1-B3 E1-E3
  • 5.3.3. B5-B6 E5-E6
  • 5.3.4. B7-B8 E7-E8
  • 5.4. Truck dimensions
  • 5.4.1. Dimensions (mm)
  • 5.4.2. B5-B6/ E5-E6
  • 5.4.3. B7-B8/ E7-E8
  • 5.5. Identification plate, truck
  • 5.6. Modification plate
  • 5.7. Identification plate, mast
  • 6. Main components
  • 6.1. Hydraulic valves The valves are located to provide easy access.
  • 6.2. Battery 48 V with different Ah values.
  • 6.3. Recharging connector The battery is recharged via this permanently attached recharging connec…
  • 6.4. Control circuit fuse 10 A, BT part no. 161640-100. Fuse for electrical steering wheel 30 A, …
  • 6.5. Hydraulic unit Pump motor, pump and oil tank integrated in a compact unit.
  • 6.6. Drive unit with brake Drive motor, gears and drive wheel combined into a compact unit. Electr…
  • 6.7. Electrical steering motor Mounted with the drive gear to provide a compact design.
  • 6.8. Identification plate With model designation, serial number, year of manufacture, weight witho…
  • 6.9. Operators seat The seat is fully adjustable to provide optimal operator comfort.
  • 6.10. Serial number The serial number plate fitted to the chassis.
  • 6.11. Cover Easily swivelled to provide good access for servicing.
  • 6.12. Pedals Accelerator with optional direction selector, travel brake and safety pedal.
  • 6.13. Control console The control console can be adjusted to a suitable height and angle to obtain…
  • 6.14. Instrument panel This provides information on the trucks running time, time indication, err…
  • 6.15. Mast The mast is a clear-view model and is equipped with an identification plate with type d…
  • 6.16. Electronics All the electronics collected in a protected compartment.
  • 6.17. Drive motor fuse RR B1-3, E1-3 and N1-3 125 A, BT part no. 29584. RR B5-8 and E5-8 160 A B…
  • 6.18. Pump motor fuse RR B1-3, E1-3 and N1-3 200 A, BT part no. 29673. RR B5-6 and E5-6 250 A, B…
  • 7. Controls and instruments
  • 7.1. Emergency switch off
  • 7.2. Key switch
  • 7.3. Display
  • 7.4. Operator identification and operator parameters
  • 7.5. Switches and indicator lamps
  • 7.6. Control console
  • 7.7. Controls for control console position
  • 7.8. Operators seat
  • 7.9. Pedals
  • 7.10. Cover lock
  • 7.11. Cab tilt lock
  • 7.12. Height indicator
  • 7.13. Emergency switch off (1)
  • 7.14. Key switch (2)
  • 7.15. Display (3)
  • 7.15.1. Parking brake indicator (A)
  • 7.15.2. Direction indicator (B)
  • 7.15.3. Time display (C)
  • 7.15.4. Display of hour meter reading/error codes (D)
  • 7.15.5. Character
  • 7.16. Operator identification and operator parameters (4)
  • 7.17. Switches and indicator lamps (5)
  • 7.17.1. Character
  • 7.17.2. Symbol on the switch
  • 7.17.3. Function
  • 7.18. Control console (6)
  • 7.18.1. Steering (A)
  • 7.18.2. Horn (D)
  • 7.18.3. Height pre-selector (E)
  • 7.18.4. Function
  • 7.19. Automatic operations
  • 7.19.1. Collecting a load
  • 7.19.2. Leaving a load
  • 7.19.3. Control
  • 7.19.4. Error Codes
  • 7.19.5. Error code
  • 7.19.6. Function
  • 7.20. Controls for control console position (7)
  • 7.20.1. WARNING
  • 7.21. Operators seat (8)
  • 7.21.1. Adjustment
  • 7.21.2. Left hand handle
  • 7.22. Pedals (9)
  • 7.22.1. Safety pedal (A)
  • 7.22.2. Safety pedal with direction selector (B)
  • 7.22.3. Travel brake (C)
  • 7.22.4. Accelerator (D)
  • 7.22.5. Accelerator and direction selector (E)
  • 7.23. Cover lock (10)
  • 7.24. Cab tilt lock (11)
  • 7.24.1. WARNING
  • 7.24.2. WARNING
  • 7.24.3. DANGER
  • 7.24.4. WARNING
  • 7.25. Height indicator (12)
  • 7.26. Display and programming
  • 7.26.1. Display
  • 7.26.2. Programming
  • 7.27. Warning codes
  • 7.27.1. Character
  • 7.27.2. Code No.
  • 7.27.3. Error type
  • 7.27.4. Probable cause
  • 7.27.5. Effect on the truck
  • 7.28. Error codes
  • 7.28.1. Character
  • 7.28.2. Code No.
  • 7.28.3. Error type
  • 7.28.4. Probable cause
  • 7.28.5. Effect on the truck
  • 8. Accessories
  • 8.1. BT TLS Truck Logging System
  • 8.1.1. Logging using a code (5 digit)
  • 8.1.2. Login with error reporting (51 digit)
  • 8.1.3. Login with extra code (53 digit)
  • 8.1.4. Login with extra code and error reporting (531 digit)
  • 8.1.5. Changing the personal three digit code
  • 8.1.6. Code card
  • 8.2. Collision sensor
  • 8.2.1. WARNING
  • 8.3. Seat belt
  • 8.3.1. WARNING
  • 8.4. Load support
  • 8.5. Extension forks
  • 8.5.1. WARNING
  • 8.6. Boom attachment
  • 8.6.1. WARNING
  • 8.7. Clamping/rotating unit
  • 8.7.1. WARNING
  • 8.8. Telescopic forks
  • 8.8.1. WARNING
  • 8.9. Sideshift/fork spread
  • 8.9.1. WARNING
  • 8.10. Warning light
  • 8.11. Working light
  • 8.12. Deceleration
  • 8.13. Operator protection
  • 8.13.1. WARNING
  • 9. Driving
  • 9.1. Starting the truck
  • 9.1.1. WARNING
  • 9.1.2. WARNING
  • 9.2. Braking
  • 9.3. Deceleration
  • 9.4. Steering
  • 9.4.1. WARNING
  • 9.4.2. WARNING
  • 9.5. Parking the truck
  • 9.5.1. WARNING
  • 10. Transporting loads
  • 10.1. WARNING
  • 10.2. WARNING
  • 10.3. WARNING
  • 10.4. WARNING
  • 10.5. WARNING
  • 10.6. WARNING
  • 10.7. WARNING
  • 10.8. Collecting a load
  • 10.8.1. CAUTION
  • 10.9. Depositing a load
  • 10.9.1. CAUTION
  • 11. Battery
  • 11.1. Changing the battery
  • 11.1.1. WARNING
  • 11.1.2. When changing the battery proceed as follows
  • 11.2. Charging the battery
  • 11.2.1. GENERAL PROHIBITION
  • 11.2.2. Battery (Ah)
  • 11.2.3. Charger (A)
  • 11.2.4. Before charging
  • 11.2.5. During charging
  • 11.2.6. After charging
  • 11.3. Battery maintenance
  • 11.3.1. WARNING
  • 11.3.2. Each week
  • 11.3.3. Each month
  • 12. Daily service and function checks
  • 12.1. WARNING
  • 12.2. Pos. No.
  • 12.3. Check points
  • 13. Maintenance
  • 13.1. Safety regulations with maintenance work
  • 13.1.1. WARNING
  • 13.1.2. WARNING
  • 13.1.3. WARNING
  • 13.1.4. CAUTION
  • 13.1.5. WARNING
  • 13.2. Maintenance work that is to be carried out by the operator
  • 13.3. Maintenance work that may be carried out by trained maintenance personnel
  • 13.4. Other service and repair work.
  • 13.5. Cleaning and washing
  • 13.5.1. External cleaning
  • 13.5.2. Cleaning the motor compartment
  • 13.5.3. Electrical components
  • 13.6. Maintenance chart
  • 13.6.1. Pos. no.
  • 13.6.2. Work to carry out
  • 13.7. Oil and grease specification
  • 13.7.1. Lubricant
  • 13.7.2. Specification
  • 13.7.3. Application area
  • 13.7.4. > – 15C
  • 13.7.5. < – 15C
  • 14. Transporting and storing the truck
  • 14.1. The trucks dimensions and weight as standard
  • 14.1.1. The trucks dimensions and weight
  • 14.2. Lifting the truck
  • 14.2.1. WARNING
  • 14.2.2. WARNING
  • 14.3. Towing and transporting a defective truck
  • 14.3.1. WARNING
  • 14.3.2. Character
  • 14.3.3. Symbol on the switch
  • 14.3.4. Function
  • 14.4. Storing the truck
  • 14.4.1. Battery
  • 14.4.2. Hydraulic system
  • 14.4.3. Drive unit
  • 14.5. Starting after a period of disuse
  • 15. Recycling/discarding
  • 15.1. Discarding the battery
  • 15.2. Scrapping the truck
  • 15.2.1. Chassis
  • 15.2.2. Hydraulic system
  • 15.2.3. Electrical system
