Bucyrus 30MB3 Continuous Miner Technical Manual BI643668
Bucyrus 30MB3 Continuous Miner Technical Manual BI643668 - Image 2
Bucyrus 30MB3 Continuous Miner Technical Manual BI643668 - Image 3
Bucyrus 30MB3 Continuous Miner Technical Manual BI643668 - Image 4
Bucyrus 30MB3 Continuous Miner Technical Manual BI643668 - Image 5

Bucyrus 30MB3 Continuous Miner Technical Manual BI643668

$30.00

  • Type Of Manual: Technical Manual
  • Manual ID: BI643668
  • Number of Pages: 284
  • Size: 18.8MB
  • Format: PDF
Category:

Product details

  • Model List:

    • 30MB3 Continuous Miner
  • 1. Technical Manual Cover Page Compatibility Mode.pdf
  • 2. Technical Manual Contents
  • 3. Section 01 Handbook Objective
  • 4. Section 02 Notes to the Operator
  • 5. Section 03 Machine Safety Stops – Isolation and Tagging Procedures
  • 6. Section 04 Access On Off Machine
  • 7. Section 05 Machine Description
  • 8. Section 06 Isolators Push buttons Switches
  • 9. Section 07 Radio Remote Control System
  • 10. Section 08 Remote Control Transmitter
  • 11. Section 09 Graphics Display Screens
  • 12. Section 10 Electrical Schematics
  • 13. Section 11 General Electrical
  • 14. Section 12 Electrical Component Layouts
  • 15. Section 13 Hydraulic General
  • 16. Section 14 Water General
  • 17. Section 15 Main Frame Assembly
  • 18. Section 16 Hydraulic Pump Assembly
  • 19. Section 17 Cutter Head Assembly
  • 20. Section 18 East-West Gathering and Conveyor Assembly
  • 21. Section 19 Traction Drive Assembly
  • 22. Section 20 Stabiliser Assembly
  • 23. Section 21 Troubleshooting
