Bucyrus 495HR2 Mining Shovel Maintenance Manual BI619624
Bucyrus 495HR2 Mining Shovel Maintenance Manual BI619624 - Image 2
Bucyrus 495HR2 Mining Shovel Maintenance Manual BI619624 - Image 3
Bucyrus 495HR2 Mining Shovel Maintenance Manual BI619624 - Image 4
Bucyrus 495HR2 Mining Shovel Maintenance Manual BI619624 - Image 5

Bucyrus 495HR2 Mining Shovel Maintenance Manual BI619624

$30.00

  • Type Of Manual: Maintenance Manual
  • Manual ID: BI619624
  • Number of Pages: 498
  • Size: 17.6MB
  • Format: PDF
Category:

Product details

  • Model List:

    • 495HR2 Mining Shovel
  • 1. Safety Precautions
  • 1.1. General Precautions
  • 1.2. Maintenance Precautions
  • 1.3. Operating Precautions
  • 1.4. Fire Prevention
  • 1.5. Warning Signs And Decals
  • 2. Introduction
  • 3. General Information
  • 3.1. SWINGING RESTRAINT BALLAST BOX SUPPORT
  • 3.2. Ballast Box Support
  • 3.3. Swinging Restraint
  • 4. Machine Overview
  • 5. Lower Works
  • 5.1. Crawlers
  • 5.2. Truck Frame
  • 5.3. Swing Rack
  • 5.4. Roller Circle
  • 5.5. Propel Machinery
  • 5.6. Collector Rings
  • 6. Rotating Deck
  • 6.1. Revolving Frame
  • 6.2. Center Pintle
  • 6.3. Deck Extensions
  • 6.4. Ballast Box
  • 6.5. Machinery House
  • 6.5.1. Boarding Stairs
  • 6.5.2. Vertical Boarding Ladder
  • 6.6. A-Frame
  • 6.7. Hoist Machinery
  • 6.8. Swing Machinery
  • 6.9. Crowd Machinery
  • 6.10. OPERATORS CAB
  • 6.11. Compressed Air System
  • 6.12. Automatic Lubrication System
  • 6.13. Lube Reservoir fill / Overflow Plumbing
  • 7. Front End Equipment
  • 7.1. Suspension Strands
  • 7.2. Running Ropes
  • 7.3. Saddle Block
  • 7.4. Dipper Handle
  • 7.5. Padlocks
  • 7.6. Dipper Trip
  • 8. Typical Machine Specifications
  • 9. General Estimated Component Weights
  • 9.1. Lower Works
  • 9.2. Upper Works
  • 9.3. Front End
  • 10. Lubrication
  • 11. Lubrication Principles
  • 12. Greasing Main A.C. Drive Motors
  • 12.1. Type of Grease
  • 12.2. Initial Commissioning
  • 12.3. Maintenance
  • 12.4. Regreasing Intervals
  • 13. Lubricant Selection
  • 14. Oil Fill Capacities
  • 14.1. Types Of Lubricants And Capacities Guidelines
  • 14.1.1. Quantities for First Fill of Lubricants
  • 15. Automatic Lubrication System
  • 15.1. Lube Room
  • 15.2. Lube Reservoir fill / Overflow Plumbing
  • 15.2.1. Auto Lube Control Panel
  • 15.3. Lower Works Lubrication
  • 15.4. Propel Machinery Lubrication
  • 15.4.1. Lubricant Replacement/sampling
  • 15.5. Revolving Frame Lubrication
  • 15.6. Hoist Machinery Lubrication
  • 15.6.1. Hoist Oil Cooler
  • 15.6.2. Filter Element Cleaning
  • 15.7. Hoist Rope Rollers Lubrication
  • 15.7.1. Oil Pump
  • 15.8. Crowd Machinery Lubrication
  • 15.9. Swing Machinery Lubrication
  • 15.10. Air Compressor Lubrication
  • 15.11. Crowd Rope Take-Up Mechanism Lubrication
  • 15.12. Front End Lubrication
  • 15.13. Lincoln Type SL-1 Lubricant Injectors
  • 15.13.1. SL-1 Lubricant Injector Operation
  • 15.13.2. Injector Advantages
  • 15.14. ACSL – Air Compressor (Screw-Type) Lubricant
  • 15.15. MPO – Multipurpose OIL
  • 15.16. RWRL – Running Wire Rope Lubricant
  • 15.17. EGL – Enclosed Gearcase Lubricant
  • 15.18. MPG – Multipurpose Grease
  • 15.19. OGL – Open Gear Lubricant
  • 15.20. Certified Lubricants Listing
  • 16. Preventive Maintenance
  • 17. Introduction
  • 17.1. Preventive Maintenance Program
  • 17.2. Elements of an Effective Maintenance Program
  • 17.3. Scheduled Preventive Maintenance Program
  • 17.4. General Safety Considerations
  • 18. Maintenance During Machine Operation
  • 18.1. Maintenance Precautions
  • 19. Preventive Maintenance for Lubrication
  • 19.1. Lubricant Cleanliness
  • 20. Frequency of Inspection and Maintenance
  • 21. Maintenance Schedules
  • 21.1. Maintenance Inspection Check Points
  • 21.1.1. Every 100 Hours or Weekly
  • 21.1.2. Every 500 Hours Or Monthly
  • 21.1.3. Every 1250 Hours or Quarterly
  • 21.1.4. Every 2500 Hours or Semi-Annually
  • 21.1.5. Hours or Annually
  • 22. Major Component Locations
  • 23. Service Procedures
  • 24. Lower Works
  • 24.1. Truck Frame Assembly
  • 24.2. Swing Rack Assembly
  • 24.2.1. Roller Circle Rail Replacement – Lower
  • 24.2.2. Roller Circle Rail Replacement – Upper
  • 24.3. Roller Circle Assembly
  • 24.3.1. Roller Circle Adjustment
  • 24.3.2. Adjustment Procedure
  • 24.3.3. Run-in Procedure for the Roller Circle
  • 24.3.4. Roller Circle Segment Removal
  • 24.3.5. Roller Circle – Roller Replacement
  • 24.4. Crawler Belts
  • 24.4.1. Crawler Belt Maintenance
  • 24.5. Crawler Side Frame Assembly
  • 24.5.1. Crawler Side Frame Maintenance
  • 24.5.2. Slide Bar Replacement
  • 24.6. Crawler Front Idler Roller Assembly
  • 24.6.1. Load and Idler Rollers
  • 24.7. Propel Assembly
  • 24.7.1. Installation Notes
  • 24.7.2. Main Propel Drive Shaft Removal
  • 24.7.3. Main Propel Shaft – Disassembly
  • 24.7.4. Tumbler Rebuild Procedure
  • 24.8. Propel Machinery
  • 24.8.1. Propel Gearcase Removal
  • 24.8.2. Propel Gearcase Installation
  • 24.8.3. Propel Planetary Gearcase
  • 24.8.4. Propel Motors
  • 25. Rotating Deck
  • 25.1. Revolving Frame
  • 25.2. Center Pintle
  • 25.2.1. Center Pintle Adjustment
  • 25.2.2. Center Pintle Sleeve Removal
  • 25.3. Collector Rings
  • 25.3.1. Collector Ring Inspection
  • 25.3.2. Collector Ring Repair
  • 25.4. Cable Reel
  • 25.5. Swing Machinery
  • 25.5.1. Swing Support Mounting Bolts
  • 25.5.2. Swing Motor
  • 25.5.3. Swing Planetary Gearcase
  • 25.5.4. Swing Pinion Shafts
  • 25.6. Hoist Machinery
  • 25.6.1. Hoist Motor Removal
  • 25.6.2. Motor Coupling Shaft
  • 25.6.3. Hoist Gearcase Assembly
  • 25.6.4. Hoist Gearcase Repair
  • 25.6.5. Hoist Drum Assembly
  • 25.6.6. Hoist Oil Cooler
  • 25.6.7. Hoist Mounting Bolts
  • 25.6.8. Hoist Limit Switch
  • 25.7. Crowd Machinery
  • 25.8. GEARCASE REPAIR
  • 25.8.1. Crowd Gearcase Disassembly
  • 25.8.2. Crowd Gearcase Assembly
  • 25.8.3. Crowd Motor
  • 25.9. Operators Cab Mounting
  • 25.10. JOYSTICK REPLACEMENT
  • 25.10.1. JOYSTICK CALIBRATION
  • 25.11. Wiper Arm Replacement
  • 25.11.1. Wiper Blade Replacement
  • 25.11.2. Wiper MOTOR REPLACEMENT
  • 25.12. Machinery House
  • 25.13. Walkways, Stairways, and Handrails
  • 25.13.1. Boarding Stairs
  • 25.13.2. Vertical Boarding Ladder, left
  • 26. Front End Equipment
  • 26.1. Boom Assembly
  • 26.2. Boom Repair
  • 26.3. Boom Limit Switch Installation
  • 26.4. Boom Point Sheaves
  • 26.4.1. Boom Point Sheave Removal and Disassembly
  • 26.4.2. Boom Point Sheave Reassembly and Installation
  • 26.5. Boom Bumper
  • 26.6. Saddle Block
  • 26.6.1. Saddle Block Repair
  • 26.6.2. Saddle Block Removal
  • 26.7. Dipper Handle
  • 26.7.1. Dipper Handle Removal
  • 26.7.2. Crowd Rope Take-Up Mechanism
  • 26.7.3. Retract Rope Take-up Mechanism
  • 26.7.4. Spreader Repair
  • 26.8. Dipper Assembly
  • 26.8.1. Latch Bar Adjusting
  • 26.8.2. Dipper Door bumpers
  • 26.8.3. Dipper Removal Installation
  • 26.8.4. Dipper Door Snubbers
  • 26.8.5. Dipper Pitch Brace
  • 26.8.6. Dipper Padlock
  • 26.8.7. Dipper Trip Assembly
  • 26.9. A-Frame
  • 26.10. Auxiliary Winch
  • 26.11. Hoist Rope Support Roller
  • 26.12. Boom Support Ropes
  • 26.13. Wire Ropes
  • 26.13.1. Wire Rope Inspection
  • 26.14. Crowd Rope Take-up Hydraulic Unit
  • 26.15. Hoist Rope Reeving Replacement
  • 26.16. Crowd Rope Reeving Replacement
  • 26.17. Retract Rope Reeving Replacement
  • 26.18. Crowd Rope Tightening
  • 26.19. Retract Rope Tightening
  • 26.20. Dipper Trip Rope Reeving Replacement
  • 26.21. Hoist and Crowd Limit Systems
  • 26.21.1. Setting Limits In The Hoist Crowd System
  • 27. Brakes and Couplings
  • 27.1. Disc Brake Operation
  • 27.2. Maintenance
  • 27.3. Brake Adjustment Specifications
  • 27.4. Hoist Brake
  • 27.4.1. Hoist Brake Adjustment
  • 27.4.2. Hoist Brake Installation
  • 27.4.3. Hoist Brake Wear Release Switches
  • 27.5. Crowd Brake
  • 27.5.1. Crowd Brake Installation
  • 27.5.2. Crowd Brake Wear Release Switches
  • 27.6. Propel Brake
  • 27.6.1. Propel Brake Adjustment
  • 27.6.2. Propel Brake Installation
  • 27.6.3. Tachometer Mounting Alignment
  • 27.7. Swing Brake
  • 27.7.1. Swing Brake Installation
  • 27.7.2. Swing Brake Wear Release Switches
  • 27.7.3. Swing Brake Burnishing
  • 27.8. Spring Replacement All Brakes
  • 27.9. Friction Disc Replacement All Brakes
  • 27.10. O-Ring Replacement All Brakes
  • 27.11. Brake Wear Release Switches Single Disc Brakes
  • 27.12. Brake Wear Release Switches Multiple Disc Brakes
  • 28. Couplings
  • 28.1. Grid Couplings
  • 28.1.1. Lubrication
  • 28.1.2. Coupling Disassembly and Grid Removal
  • 28.1.3. Grid Coupling Installation
  • 28.1.4. Seal Replacement without Hub Removal
  • 28.1.5. Grid Coupling Alignment
  • 28.2. Gear Couplings
  • 28.2.1. Coupling Installation
  • 28.2.2. Gear Coupling Alignment
  • 28.2.3. Hoist Coupling Shaft Alignment
  • 29. Compressed Air System
  • 30. Air Compressor
  • 30.1. Lockout Valves
  • 30.2. Safety Warnings
  • 31. Air Filtration
  • 32. House Filter Fans
  • 32.1. Lubrication
  • 32.2. Dynavane Air Cleaner
  • 33. Air Conditioner/heater
  • 33.1. Evaporator
  • 33.2. Condenser
  • 33.3. Pressurizer
  • 33.3.1. Cleaning The Washable Filter
  • 33.4. Specifications
  • 34. Engineering Data
  • 35. Capscrew (Bolt) Grade
  • 35.1. Bolt Tightening
  • 35.1.1. Torque Wrench Method
  • 35.1.2. Turn-of-nut Method
  • 36. Measurement Systems
  • 36.1. Linear Measurements
  • 36.2. Area Measurements
  • 36.3. Volume Measurements
  • 36.4. Torque Measurements
  • 36.4.1. Weight Measurements – Conventional
  • 37. Split Flange Assembly Procedure
  • 38. Wire Locking Capscrews
  • 39. Torque Nut Installation
  • 40. Expansion Bolt Installation
  • 40.1. Tightening Procedure for 1.25-Inch Torque Nut
  • 40.2. Tightening Procedure for 2-Inch Torque Nut
  • 40.3. Tightening Procedure for 2-Inch Torque Nut
  • 40.4. Tightening Procedure for 2-Inch Torque Nut
  • 40.5. Tightening Procedure for 2.5-Inch Torque Nut
  • 40.6. Tightening Procedure for 3-Inch Torque Nut
  • 40.7. Tightening Procedure for 3.5-Inch Torque Nut
  • 40.8. Procedure For Use Of Mechanical Tensioner On 3.5 Inch Crawler Rods
  • 40.8.1. Initial Tensioning
  • 40.8.2. Final Tensioning
  • 40.9. Tightening Procedures – Expansion Bolts
  • 40.9.1. Rack Roller Torque Rod, Tapered Sleeve 1.0 Inch Torque Nut
  • 40.9.2. Hoist Torque Rod, Tapered Sleeve 1.62 Inch Torque Nut
  • 40.9.3. Swing Torque Rod Tapered Sleeve 3.25 Inch Torque Nut
  • 41. Torque Nut Removal Procedure
  • 41.1. Thread Lubrication
  • 42. Torque Nut Helpful Hints
  • 43. Locking Assemblies
  • 43.1. Locking Assembly Removal
  • 44. Pinion and Hub Installation
  • 44.1. Removal from a Shaft
  • 44.2. Mounting a Pinion or Hub on a Shaft
  • 44.2.1. Pre-heat Advance Requirements – Pinions and Hubs
  • 44.2.2. Motor Coupling Pre-Heat Advance Requirements
  • 45. Maintenance Welding
  • 45.1. Welding Electrodes
  • 45.2. Repair Welding of Cracks
  • 45.2.1. Preheat
  • 45.2.2. Welding Technique
  • 45.3. Repair Welding of Broken Parts
  • 45.4. Repair Welding Swing Rack Teeth
  • 45.4.1. Preparation
  • 45.4.2. Swing Rack Welding Electrodes
  • 45.4.3. Preheat
  • 45.4.4. Welding Procedure
  • 45.5. Welding and Cutting Equipment
  • 45.6. Stress Relieving Temperature Measuring Equipment
  • 46. Wire Rope Care and Maintenance
  • 46.1. Storage
  • 46.2. Checking Diameter
  • 46.3. Handling Wire Rope
  • 46.4. Seizing Wire Rope
  • 46.5. End Preparations/Terminations
  • 46.6. Wire Rope Clips
  • 46.6.1. Wire Rope Clip Application
  • 46.6.2. Wedge Sockets
  • 46.7. Inspection of Sheaves and Drums
  • 46.8. Breaking In a New Wire Rope
  • 46.9. Inspection Data
  • 46.10. Guideline to Inspections and Reports
  • 46.10.1. Wire Rope Inspection Criteria
  • 46.11. Seal Installation
  • 46.12. Gearcase Sealing
  • 47. Schematics
  • 48. Schematics
  • 49. Side View
  • 50. Deck Plan
  • 51. HVAC Schematic
  • 52. OGL System A B Schematic
  • 53. Grease System C Schematic
  • 54. Air Schematic
  • 55. ServiceProcedures X32.pdf
Rate this product

Related products
