Bucyrus 7MFBHM-48DD Feeder Breaker Operation And Maintenance Manual A6474X338
Bucyrus 7MFBHM-48DD Feeder Breaker Operation And Maintenance Manual A6474X338 - Image 2
Bucyrus 7MFBHM-48DD Feeder Breaker Operation And Maintenance Manual A6474X338 - Image 3
Bucyrus 7MFBHM-48DD Feeder Breaker Operation And Maintenance Manual A6474X338 - Image 4
Bucyrus 7MFBHM-48DD Feeder Breaker Operation And Maintenance Manual A6474X338 - Image 5

Bucyrus 7MFBHM-48DD Feeder Breaker Operation And Maintenance Manual A6474X338

$30.00

  • Type Of Manual: Operation And Maintenance Manual
  • Manual ID: A6474X338
  • Number of Pages: 246
  • Size: 17.8MB
  • Format: PDF
Category:

Product details

  • Model List:

    • 7MFBHM-48DD Feeder Breaker
  • 1. 1. About this manual
  • 2. About this manual ………………………………………………………… 1.3
  • 3. Before starting to work………………………………………………… 1.3
  • 4. Who is this operating manual intended for? …………………… 1.3
  • 5. What is the purpose of this operating manual? ………………. 1.4
  • 6. Characters and symbols ……………………………………………… 1.5
  • 7. 2. Your safety
  • 8. Your safety …………………………………………………………………… 2.3
  • 9. Personnel………………………………………………………………….. 2.4
  • 10. Operation ……………………………………………………………… 2.4
  • 11. Installation and repair……………………………………………… 2.4
  • 12. Operating conditions…………………………………………………… 2.5
  • 13. Intended use …………………………………………………………. 2.5
  • 14. Unauthorized use…………………………………………………… 2.5
  • 15. Safety instructions………………………………………………………. 2.7
  • 16. General rules: ……………………………………………………….. 2.7
  • 17. Storage and transport …………………………………………….. 2.9
  • 18. Installation and start-up…………………………………………… 2.9
  • 19. Operation ……………………………………………………………..2.10
  • 20. Maintenance and repair ………………………………………….2.10
  • 21. 3. Storage and transport
  • 22. Storage and transport …………………………………………………… 3.3
  • 23. Storage …………………………………………………………………….. 3.3
  • 24. Storage of the machine and spare parts……………………. 3.3
  • 25. Transport…………………………………………………………………… 3.4
  • 26. Before transport …………………………………………………….. 3.6
  • 27. 4. Installation
  • 28. Installation……………………………………………………………………. 4.3
  • 29. Points to observe prior to installation…………………………….. 4.3
  • 30. Who is allowed to carry out installation?……………………. 4.3
  • 31. Which tools are required for installation?…………………… 4.3
  • 32. Notes on installation……………………………………………….. 4.4
  • 33. Pre-installation check list ………………………………………… 4.5
  • 34. Safety features………………………………………………………. 4.6
  • 35. Towing the feeder breaker…………………………………………… 4.9
  • 36. 5. Operation
  • 37. Operation ……………………………………………………………………… 5.3
  • 38. How to operate the feeder breaker ………………………………. 5.3
  • 39. Who is allowed to operate the feeder breaker …………… 5.3
  • 40. When can conveying be started?……………………………… 5.3
  • 41. Controls and indicators ……………………………………………….. 5.4
  • 42. Primary operator’s station ……………………………………….. 5.4
  • 43. Secondary operator’s station …………………………………..5.10
  • 44. Left side of machine ……………………………………………….5.13
  • 45. Right center of machine ………………………………………….5.13
  • 46. Starter enclosure……………………………………………………5.14
  • 47. Control features……………………………………………………..5.16
  • 48. “REGULAR” mode starting procedure …………………………..5.17
  • 49. “TRAM ONLY” mode starting procedure………………………..5.18
  • 50. Shutdown procedure…………………………………………………..5.19
  • 51. Conveyor…………………………………………………………………..5.20
  • 52. Infrared pump motor controls……………………………………….5.21
  • 53. Electrical system ………………………………………………………..5.23
  • 54. Starter enclosure……………………………………………………5.24
  • 55. Hydraulic system………………………………………………………..5.31
  • 56. Major hydraulic components ………………………………5.32
  • 57. Mechanical assemblies……………………………………………….5.37
  • 58. Crawler assembly (s) …………………………………………….5.37
  • 59. Conveyor chain …………………………………………………….5.38
  • 60. Grease take-up …………………………………………………….5.38
  • 61. Head shaft ……………………………………………………………5.39
  • 62. Conveyor power unit ……………………………………………..5.40
  • 63. Tail shaft ………………………………………………………………5.40
  • 64. Breaker and breaker power unit assembly ………………..5.41
  • 65. Tailpiece assembly…………………………………………………5.43
  • 66. Instructions on the maintenance of the feeder ……………….5.45
  • 67. Important notes …………………………………………………….5.45
  • 68. Before maintenance ………………………………………………5.45
  • 69. Lubrication and inspection ……………………………………..5.50
  • 70. Specific lubrication and maintenance procedures ………….5.52
  • 71. Every 8 hours of operation ……………………………………..5.52
  • 72. Weekly …………………………………………………………………5.55
  • 73. Every 2 weeks ………………………………………………………5.59
  • 74. Monthly ………………………………………………………………..5.59
  • 75. Every 3 months …………………………………………………….5.61
  • 76. Every 2500 hours …………………………………………………..5.64
  • 77. Every 6 months …………………………………………………….5.65
  • 78. Inspection of the feeder ……………………………………………..5.67
  • 79. Inspection of wear parts on the feeder ………………………….5.68
  • 80. Inspection of the fire suppression system………………………5.69
  • 81. Recharge of the fire suppression system……………………….5.71
  • 82. Instructions on the adjustment procedures ……………………5.73
  • 83. Conveyor chain adjustment …………………………………….5.73
  • 84. Crawler track adjustment ……………………………………….5.75
  • 85. Under speed sensor calibration ……………………………….5.77
  • 86. Hydrostatic pump relief valve adjustment ………………….5.79
  • 87. Hydrostatic pump charge pressure adjustment ………….5.81
  • 88. Loop flushing valve adjustment………………………………..5.84
  • 89. Dual relief valve manifold adjustment………………………. 5.86
  • 90. Secondary valve bank adjustment ………………………….. 5.89
  • 91. Flow control valve adjustment ………………………………… 5.91
  • 92. Instructions on the replacement of wear parts ……………… 5.93
  • 93. Head shaft ………………………………………………………….. 5.93
  • 94. Head shaft sprockets ……………………………………………. 5.97
  • 95. Tail shaft …………………………………………………………….5.100
  • 96. Conveyor chain ……………………………………………………5.105
  • 97. Crawler track ………………………………………………………5.108
  • 98. Crawler assembly ………………………………………………..5.111
  • 99. Breaker shaft and breaker power unit …………………….5.119
  • 100. Conveyor power unit……………………………………………..5.127
  • 101. Breaker bit removal ………………………………………………5.134
  • 102. Tailpiece installation ……………………………………………..5.135
  • 103. Roof cylinder………………………………………………………..5.139
  • 104. Foot cylinder ………………………………………………………..5.141
  • 105. Tilt cylinder ………………………………………………………….5.143
  • 106. Lift cylinder ………………………………………………………….5.145
  • 107. Tailpiece tilt cylinder ……………………………………………..5.147
  • 108. Tailpiece steering cylinder……………………………………..5.149
  • 109. 6. Technical data
  • 110. Technical data ……………………………………………………………….6.3
  • 111. Components of the feeder breaker ………………………………..6.3
  • 112. Tightening torques……………………………………………………….6.7
  • 113. Permissible data………………………………………………………….6.9
  • 114. Lubrication fluids and greases…………………………………..6.9
  • 115. 7. For your information
  • 116. For your information………………………………………………………7.3
  • 117. Our service …………………………………………………………………7.3
  • 118. Service address………………………………………………………7.3
  • 119. Rebuild facility address…………………………………………….7.4
