Bucyrus RH200 Face Shovel General Parts Catalog BI638291
Bucyrus RH200 Face Shovel General Parts Catalog BI638291 - Image 2
Bucyrus RH200 Face Shovel General Parts Catalog BI638291 - Image 3
Bucyrus RH200 Face Shovel General Parts Catalog BI638291 - Image 4
Bucyrus RH200 Face Shovel General Parts Catalog BI638291 - Image 5

Bucyrus RH200 Face Shovel General Parts Catalog BI638291

$30.00

  • Type Of Manual: Parts Catalog
  • Manual ID: BI638291
  • Number of Pages: 496
  • Size: 12.0MB
  • Format: PDF
Category:

Product details

  • Model List:

    • RH200 Face Shovel General
  • 1. UNDERCARRIAGE
  • 2. Under Carriage 40002-40024, 40033
  • 3. Under Carriage 40025-40028
  • 4. Under Carrage 40031, 40035-On
  • 5. LOWER CARRIAGE S N 40045 – ON
  • 6. Sprocket Wide 40002 3 5 6, 40025 – 40031
  • 7. Sprocket Narrow 40004, 40016 – 40024 40033
  • 8. Travel gearbox 40002 – 40023 Superceeded
  • 9. Travel Gearbox 40024, 40025, 40031, 40033
  • 10. Travel Gearbox 40002-On
  • 11. TRAVEL GEAR S N 40045 – ON
  • 12. Hydraulic Travel Motor 40002 – On
  • 13. HYDRAULIC MOTOR S N 40026 – 40047
  • 14. Track Tensioning Front Idler 40002- On
  • 15. Track Tensioning 40002
  • 16. Track Chain With Bolt On Pin Retainers
  • 17. Track Chain Australian 50mm
  • 18. CHASSIS S N 40024 40025
  • 19. Track Chain Circlip Pin Retension
  • 20. DRIVING CHAIN S NO
  • 21. Load Roller 370mm DIA Superseded to 410mm DIA
  • 22. Load Roller 410mm Dia
  • 23. Under Carriage Hydraulic System 40002 On
  • 24. Rotor 40002 – On
  • 25. Travel Brake 40002 – On
  • 26. Carrier Roller 40002 – 40008
  • 27. Carrier Roller 40016 – On
  • 28. TIGHTENING DEV
  • 29. Hydraulic Track Tensioning 40002 – 40028
  • 30. Hydraulic Track Tensioning 40031 – On
  • 31. Upper Carriage 40002 – 40028 40033
  • 32. Upper Carriage Frame 40031, 40035 40035n – On
  • 33. S STRUCTURE FRAME S N 40045 – ON
  • 34. Greasing System 40002 – 40023
  • 35. Greasing System 40024 – On
  • 36. LUBRICATION SYSTEM S N 40045 – ON
  • 37. Operators Cab 40002 – 40006
  • 38. Operators Cab 40008 – 40024
  • 39. Operators Cab 40025
  • 40. Operators Cab 40026 – On
  • 41. CAB S N 40045 – ON
  • 42. CAB S N 40045 – ON
  • 43. Railings Grids 40002 – 40028 40033
  • 44. Railings Grids 40031, 40035 40035 – On
  • 45. FOPS 40002 – 40016
  • 46. FOPS S N 40023 On
  • 47. FOPS S N 40045 – ON
  • 48. Operators Seat 40002 – 40028 40033
  • 49. Operators Seat
  • 50. Operators Seat 40031 40035 – On
  • 51. Platform Plate 40002 – 40028 40033
  • 52. Platform Plate 40031, 40035 On
  • 53. PLATFORM PLATE S N 40045 – ON
  • 54. Engine Mountings 40002 – 40028 40033
  • 55. Engine Mountings 40031 40035 On
  • 56. ENGINE MOUNTING S N 40045 – ON
  • 57. Exhaust System 40002 – 40028 40033
  • 58. Exhaust System S N 40031
  • 59. INTAKE SYSTEM S N 40016 – 40031
  • 60. Air Intake System 40002 – 40028 40033
  • 61. Air Intake System, 40031, 40035 – On
  • 62. Cooling System 40002 – 40028, 40033
  • 63. Cooling System 40002 – 40028, 40033
  • 64. Cooling System 40031, 40035 On
  • 65. Water Radiator 40002 – 40028, 40033
  • 66. Hydraulic System Crane (Tico) S NO
  • 67. Switch Cabinet 40002 – 40028, 40033
  • 68. Engine Casing 40002 – 40028, 40033
  • 69. Engine Casing 40002 – 40028, 40033
  • 70. Tool Box S NO
  • 71. Tool Box S NO
  • 72. Engine Coupling 40002 – On
  • 73. Engine Coupling 40002 – On
  • 74. Fuel System 40002 – On
  • 75. Fuel System 40025 – On
  • 76. Filler System 40002 – 40024
  • 77. Filler System 40025 – 40028, 40033
  • 78. Filler System 40031, 40035 – On
  • 79. Slew Gearbox (With Drum Brake)
  • 80. Slew Gearbox
  • 81. Slew Gearbox (With Hydraulic Brake) Long Pinion
  • 82. HYDRAULIC MOTOR S NO
  • 83. SLEW BRAKE S N 40002 – 40023
  • 84. Slew Brake (Hydraulic Low Profile ) S NO
  • 85. Swing Brake (Hydraulic High Profile ) S NO
  • 86. Hydraulic Delivery Cooler 40002 – 40023 40033
  • 87. Hydraulic Delivery Cooler S NO
  • 88. Compressed Air System 40002 – 40006
  • 89. Compressor Air System 40016 – 40023 40033
  • 90. Compressor Air System 40024 – 40031
  • 91. Compressor Air System 40016 – 40023 40033
  • 92. Switch Cabinet 40016 – 40023 40033
  • 93. Switchboard 40016 – 40033
  • 94. Battery Installation 40002 – On
  • 95. Plate 40002 – On
  • 96. Cooler Cab Module 40002 – 40028, 40033
  • 97. Cooler Cab Module 40031 – On
  • 98. Washer 40002 – On
  • 99. Wiper Washer System 40002 – ON
  • 100. HYD SYSTEM P FORM S NO
  • 101. HYD SYSTEM P FORM S NO
  • 102. HYDRAULIC SYSTEM S N 40002 – 40023
  • 103. SERVO SYSTEM 40002 – 40016 40033
  • 104. Hydraulic System 40031, 40035 – On
  • 105. HYDRAULIC SYSTEM S N 40045 – ON
  • 106. Hydraulic System 40002 – 40028, 40033
  • 107. Hydraulic System 40002 – 40023, 40033
  • 108. Hydraulic System 40025 – 40028
  • 109. Hydraulic System 40031, 40035 – On
  • 110. Valve Control 40002 – 40023 40033
  • 111. Hyd. System Pump Control S NO
  • 112. Pump Governing 40002 – 40028, 40033
  • 113. Servo System-Pumps S NO
  • 114. Hyd System Travel S No
  • 115. Hyd. System Travel S No
  • 116. Hyd. System Travel S No
  • 117. Hydraulic System 40002 – 40023, 40033
  • 118. Slew Circuit 40024 – 40028
  • 119. SLEW CIRCUIT HYDRAULIC SYSTEM 40031 – 40035
  • 120. HYD SYSTEM- SLEW S N 40045 – ON
  • 121. Hyd. System Boom Valve S No
  • 122. Hyd. System Boom Valve S No
  • 123. Hydraulic System S No
  • 124. Hydraulic Oil Tank 40002 – 40024
  • 125. Hydraulic Oil Tank 40025 – 40028 40033
  • 126. Hydraulic Oil Tank 40031 40035 – On
  • 127. Hydraulic Pump Hoses Fittings 40002 – 40028, 40033
  • 128. Oil Cooling 40002 – 40023
  • 129. HYD SYS OIL COOLING 40002 – 40023
  • 130. Cooling Hydraulic System 40024 – 40028
  • 131. Oil Cooling 40031 – 40035 – On
  • 132. Pump Drive Gearbox 40002 – On
  • 133. Oil Cooling 40002 – On
  • 134. Working Pump 40002 – 40023, 40033
  • 135. Main Pump Hyd. Oil S No
  • 136. Main Pump Hyd Oil S No
  • 137. Servo Pump 40002 – On
  • 138. Servo Valve 40002 – On
  • 139. Spool Block 40002 – On
  • 140. L H Travel Valve 40002 – 40028
  • 141. L H Travel Valve 40031 – On
  • 142. R H Travel Valve 40002 – 40028
  • 143. R H Travel Valve 40031 – On
  • 144. Float Valve 40002 – On
  • 145. Servo Valve 40028, 40031-On
  • 146. Joy Stick 40002 – 40027, 40033
  • 147. VALVE EQUIPMENT S N 40045 – ON
  • 148. Treadle Valve 40002-On
  • 149. Tank Line Return Valve 40002 – On
  • 150. VALVE PRETENSION S N 40045 – ON
  • 151. Pressure Balance Valve 40002-On
  • 152. Hydraulic Cooling Fan Motor 40002 – 40006
  • 153. Hydraulic Cooling Fan Motor 40016 – On
  • 154. Cooling Pump 40002-On
  • 155. Slew Pump 40002-On
  • 156. Servo Pump 40002 – On
  • 157. NON RETURN VALVE S N 40016 – 40023
  • 158. Swing Circuit Filter 40002- On
  • 159. Check Valve 40002 – On
  • 160. Pump Distributor 40002 – On
  • 161. Cooling Distributor 40002-On
  • 162. Solenoid Valve 40002 – On
  • 163. Servo Valve 40002 – On
  • 164. Proportional Valve 40002 – On
  • 165. Shift Valve Y32 Y33 40002 – On
  • 166. Travel Retarder Valve 40002 – 40028
  • 167. Travel Retarder Valve 40031 – On
  • 168. Travel Retarder Valve 40031 – On
  • 169. Slew Blocking Valve 40002 – On
  • 170. Arm Stick Shovel S No
  • 171. Arm Stick Shovel S NO
  • 172. STICK SHOVEL S N 40026
  • 173. Arm Stick To Boom Pin 40002 – On
  • 174. Boom (Trunion Type) S NO
  • 175. BOOM LWR SECT
  • 176. Boom (Floating Pin Type) 40024 – 40026
  • 177. Boom Catwalk 40002 – On
  • 178. SHOVEL REAR WALL S N 40016
  • 179. BUCKET BACKWALL 15CBM S NO
  • 180. Bucket Rear Wall 19CBM S NO
  • 181. Bucket Rear Wall 23CBM S NO
  • 182. SHOVEL FRONT SHELL S N 40016
  • 183. Buckrt Front Shell Lip 19CBM S NO
  • 184. Bucket Front Shell Lip S NO
  • 185. SHOVEL FRONT SHELL S N 40047
  • 186. Boom Cylinder 40002-40006 40016
  • 187. Boom Cylinder 40023 – 40028 40033
  • 188. Boom Cylinder 40031 40035 – On 2245517
  • 189. STICK CYLINDER S N 40016 – 40023
  • 190. Arm Stick Cylinder 40024 – 40031
  • 191. Bucket Cylinder 40002-On
  • 192. CYLINDER SHOVEL TIP S N 40017 40023
  • 193. Clam Cylinder 40002 – On
  • 194. Cylinder Guard (Elephant Ears) 40002-On
  • 195. HYD SYSTEM STICK S N 40031 40033
  • 196. Clam Cylinder Hydraulic Lines40002-On
  • 197. Hydraulic System – Attachment 40024 – 40026
  • 198. Greasing System Backwall S NO
  • 199. Greasing System Backwall S NO
  • 200. Greasing System – Arm S NO
  • 201. Greasing System – Arm S NO
  • 202. Greasing System Boom 40002 – 40006
  • 203. BOOM GREASE SYSTEM 40016 – 40023
  • 204. Boom Greasing System 40024 – On
  • 205. top page-catalog – Copy.pdf
