Caterpillar MD6290 Rotary Blasthole Drill Parts Manual BI012802
Caterpillar MD6290 Rotary Blasthole Drill Parts Manual BI012802 - Image 2
Caterpillar MD6290 Rotary Blasthole Drill Parts Manual BI012802 - Image 3
Caterpillar MD6290 Rotary Blasthole Drill Parts Manual BI012802 - Image 4
Caterpillar MD6290 Rotary Blasthole Drill Parts Manual BI012802 - Image 5

Caterpillar MD6290 Rotary Blasthole Drill Parts Manual BI012802

$30.00

  • Type Of Manual: Parts Manual
  • Manual ID: BI012802
  • Number of Pages: 864
  • Size: 30.8MB
  • Format: PDF
Category:

Product details

  • Model List:

    • MD6290 Rotary Blasthole Drill
  • 1. DS300128CVR
  • 2. PARTS MANUAL MD6290 S N DS300
  • 3. GENERAL ASSEMBLY ITEMS LIST
  • 4. SECT1.pdf
  • 4.1. SECTION 1 GENERAL LOCATOR D
  • 4.2. FILTER ELEMENTS
  • 4.3. DECAL KIT CAT YELLOW MD6290
  • 4.4. DECAL KIT WARNING
  • 5. SECT2.pdf
  • 5.1. SECTION 2 OPERATOR S CAB
  • 5.2. CAB ASSEMBLY W GAUGES AND ATTAC
  • 5.3. CAB WINDOW WIPER WASHER INSTALL
  • 5.4. WINDSHIELD WIPER SYSTEM 24 IN
  • 5.5. HARNESS WINDOW WIPER REAR
  • 5.6. HARNESS WINDOW WIPER RIGHT S
  • 5.7. HARNESS WINDOW WIPER LEFT SI
  • 5.8. HARNESS WINDOW WIPER FRONT T
  • 5.9. INTERIOR HARNESS ELECTRICAL INS
  • 5.10. HARNESS E STOP CAB
  • 5.11. HARNESS RELAY 1 AND 4
  • 5.12. HARNESS RELAY 5 2 AND 3
  • 5.13. DRILL FUNCTION PANEL ASSEMBLY W
  • 5.14. PANEL SWITCHES DRILL FUNCTIO
  • 5.15. HARNESS GATE VALVE JUNCTION
  • 5.16. HARNESS PANEL JOYSTICK
  • 5.17. HARNESS DRILL HOUR
  • 5.18. LOAD UNLOAD SWITCH W CONNECTOR
  • 5.19. FAST PULLDOWN SWITCH W CONNECTO
  • 5.20. JUMPER SEAT WITH ATTACHING HARD
  • 5.21. PANEL GAUGES HYDRAULIC
  • 5.22. CONTROL MAST JACKS
  • 5.23. INSULATION KIT CAB SPECIAL
  • 5.24. CAB HOSE PLUMBING
  • 5.25. CAB MODIFICATION ELECTRIC HAND
  • 5.26. ROTARY OPERATOR S SEAT
  • 5.27. SEAT BELT W TETHER AND HARDWARE
  • 5.28. SEAT AIR ACCUMULATOR INSTALLATI
  • 5.29. GLASS INSTALLATION CAB TINTED
  • 5.30. HEATER AIR CONDITIONER INSTAL
  • 5.31. HEATER AIR CONDITIONER PACKAG
  • 5.32. AIR CLEANER ASSEMBLY A C HEATE
  • 5.33. CONDENSER 24V
  • 5.34. WALL MOUNT UNIT W ANGLE LOUVERS
  • 5.35. BLOWER ASSEMBLY A C HEATER PRE
  • 5.36. AIR CONDITIONER HOSE KIT
  • 5.37. HARNESS CIRCUIT BREAKER A C
  • 5.38. WINDOW SHADE INSTALLATION OPER
  • 6. SECT3.pdf
  • 6.1. SECTION 3 MAINFRAME CRAWLER
  • 6.2. MAINFRAME ASSEMBLY MD6290
  • 6.3. FLOOR COVERING DUST SEALS
  • 6.4. CYLINDER MAST ELEVATING
  • 6.5. MANIFOLD INSTALLATION SUCTION
  • 6.6. COUNTERBALANCE VALVE ASSEMBLY
  • 6.7. WALKWAY INSTALLATION CAB
  • 6.8. VALVE ASSEMBLY W ATTACHMENTS D
  • 6.9. VALVE ASSEMBLY LESS ATTACHMENTS
  • 6.10. VALVE ASSEMBLY W ATTACHMENTS F
  • 6.11. VALVE ASSEMBLY LESS ATTACHMENTSZ
  • 6.12. MANIFOLD W ATTACHMENTS RETURN
  • 6.13. MANIFOLD W ATTACHMENTS CASE DR
  • 6.14. MANIFOLD W ATTACHMENTS
  • 6.15. VALVE ASSEMBLY W ATTACHMENTS R
  • 6.16. VALVE W ATTACHMENTS SHUTTLE
  • 6.17. VALVE ASSEMBLY JACKS MAST CONT
  • 6.18. VALVE ASSEMBLY JACKS MAST CONTQ
  • 6.19. VALVE ASSEMBLY W ATTACHMENTS V
  • 6.20. VALVE ASSEMBLY LESS ATTACHMENTSA
  • 6.21. HARNESS CONNECTOR LIGHTED
  • 6.22. VALVE ASSEMBLY DUST COLLECTOR
  • 6.23. VALVE ASSEMBLY DUST COLLECTORE
  • 6.24. VALVE ASSEMBLY DIVERTER W ATTA
  • 6.25. VALVE ASSEMBLY W ATTACHMENTS RY
  • 6.26. CRAWLER ASSEMBLY CAT 330EL M
  • 6.27. PROPEL PLUMBING
  • 6.28. FUEL TANK INSTALLATION W PLUMBI
  • 6.29. FUEL TANK SUBASSEMBLY
  • 6.30. JACK INSTALLATION 48
  • 6.31. CYLINDER ASSEMBLY JACK
  • 6.32. TRACK 2 SPEED PROPEL INSTALLATI
  • 6.33. HARNESS 2 SPEED INTERTRACK
  • 6.34. SWITCH 2 SPEED TRAM W CONNECTO
  • 6.35. VIEWING HATCH DRILL DECK
  • 6.36. HYDRAULIC CYLINDER
  • 6.37. VIEWING HATCH PLUMBING
  • 6.38. AUXILIARY FUEL TANK INSTALLATIO
  • 7. SECT4.pdf
  • 7.1. SECTION 4 ENGINES COMPRESSO
  • 7.2. ENGINE WITH ATTACHMENTS CAT C2
  • 7.3. COUPLING PUMP DRIVE GEARBOX TO
  • 7.4. COOLANT CONDITIONER FILTER ASSE
  • 7.5. FUEL FILTER INSTALLATION C27
  • 7.6. FUEL FILTER
  • 7.7. ELECTRICAL INSTALLATION C27
  • 7.8. ENGINE BOX ELECTRICAL ASSEMBLY
  • 7.9. HARNESS ECM C27
  • 7.10. HARNESS TAC STARTER FUEL A C
  • 7.11. HARNESS COMPRESSOR 1 C27
  • 7.12. HARNESS STARTER 1 C27
  • 7.13. HARNESS PRESSURE SWITCH WATER
  • 7.14. HARNESS 2 SPEED FUEL C27
  • 7.15. HARNESS STARTER 2 C27
  • 7.16. HARNESS ALTERNATOR C27
  • 7.17. HARNESS RELAY TO STARTER SOLEN
  • 7.18. HARNESS ALTERNATOR 2 C27
  • 7.19. ENGINE CHARGE PILOT PLUMBING
  • 7.20. ENGINE PANEL STARTUP ASSEMBLY
  • 7.21. HARNESS THROTTLE
  • 7.22. MAGNETIC SENSOR W ELECTRICAL CO
  • 7.23. ENGINE PRELUBE INSTALLATION C
  • 7.24. ENGINE PRELUBE PUMP
  • 7.25. GUARD INSTALLATION DRIVELINE
  • 7.26. AIR CLEANER INSTALLATION ENGI
  • 7.27. AIR CLEANER ASSEMBLY
  • 7.28. ENGINE WATER PIPING C27
  • 7.29. AIR CLEANER RAIN SHIELD ASSEMBL
  • 7.30. AIR COMPRESSOR ASSEMBLY 1150 3
  • 7.31. AIR COMPRESSOR PACKAGE SERVICE
  • 7.32. COMPRESSOR AIR END ATTACHMENTS
  • 7.33. RECEIVER TANK ASSEMBLY COMPRES
  • 7.34. REGULATOR CONTROL PANEL ASSEMBL
  • 7.35. SHUTDOWN SWITCH ASSEMBLY
  • 7.36. DISCHARGE VALVE ASSEMBLY
  • 7.37. TORSIONAL DRIVE COUPLING
  • 7.38. AIR CLEANER INSTALLATION COMPR
  • 7.39. COMPRESSOR AIR RECEIVER PIPIN
  • 7.40. HYDRAULIC FILTER ASSEMBLY COMP
  • 7.41. COMPRESSOR AIR RECEIVER HOSE
  • 7.42. ENGINE CHARGE AIR PIPING C27
  • 7.43. COOLER INSTALLATION
  • 7.44. COOLER ASSEMBLY W PLUMBING ENG
  • 7.45. OIL COOLER ASSEMBLY COMPRESSOR
  • 7.46. RADIATOR ASSEMBLY
  • 7.47. CHARGE AIR AFTERCOOLER ASSEMB
  • 7.48. COOLER ASSEMBLY HYDRAULIC OIL
  • 7.49. MOTOR FAN
  • 7.50. THERMOSTATIC VALVE ASSEMBLY
  • 7.51. FAN PLUMBING COOLER
  • 7.52. PUMP DRIVE ASSEMBLY
  • 7.53. PUMP DRIVE GEARBOX ASSEMBLY 3
  • 7.54. MAIN PUMP CLOSED LOOP
  • 7.55. SHAFT SEAL AND CASE DRAIN PLUG
  • 7.56. PORT PLATE HOUSING AND VALVES S
  • 7.57. PTO ADD ON SPARE PARTS LIST
  • 7.58. FILTER ELIMINATION FLANGE SPARE
  • 7.59. E1P CONTROL ASSEMBLY SPARE PART
  • 7.60. MAIN PUMP OPEN LOOP
  • 7.61. SHAFT SEAL AND CASE DRAIN SPARE
  • 7.62. HIGH PRESSURE END FLANGE PLUG A
  • 7.63. LP CONTROL ASSEMBLY LIST
  • 7.64. CHARGE PUMP
  • 7.65. GEAR PUMP FAN DUST COLLECTOR
  • 7.66. HYDRAULIC FILTER ASSEMBLY CHAR
  • 7.67. BLOWDOWN AIR HOSE ASSEMBLY
  • 7.68. MUFFLER INSTALLATION TWIN ENG
  • 7.69. EXHAUST INLET PIPE TO SILENCER
  • 7.70. EXHAUST OUTLET SILENCER CS D
  • 7.71. EXHAUST ELBOW GROUP
  • 7.72. EXHAUST INLET PIPE
  • 8. SECT5.pdf
  • 8.1. SECTION 5 DUST CONTROL
  • 8.2. COVER PLATE INSTALLATION NO DU
  • 8.3. DUST CURTAIN INSTALLATION
  • 8.4. DUST CURTAIN RAISE LOWER ASSEMB
  • 8.5. HYDRAULIC CYLINDER ASSEMBLY
  • 8.6. HYDRAULIC DUST CURTAIN LEVER
  • 8.7. DUST CURTAIN PLUMBING
  • 8.8. WATER INJECTION SYSTEM HORIZO
  • 8.9. VALVE FLOW CONTROL
  • 8.10. WATER INJECTION PLUMBING
  • 8.11. WATER PUMP MOUNT ASSEMBLY
  • 8.12. WATER PUMP ASSEMBLY HORIZONTA
  • 8.13. HYDRAULIC MOTOR
  • 8.14. WATER INJECTION FLOW METER INST
  • 9. SECT6.pdf
  • 9.1. SECTION 6 MAST
  • 9.2. MAST ASSEMBLY 11 5M
  • 9.3. MAST PIVOT BRACKET OUTSIDE
  • 9.4. CYLINDER HOIST AND PULLDOWN M
  • 9.5. GUIDE ASSEMBLY SHEAVE MAST
  • 9.6. SHEAVE 22 INCH OD W BEARING
  • 9.7. VALVE ASSEMBLY MAST 9 SECTI
  • 9.8. VALVE ASSEMBLY MAST 9 SECTIO
  • 9.9. DUST HOOD INSTALLATION
  • 9.10. MAST PLUMBING 11 5 METER MAST
  • 9.11. PIPE RACK INSTALLATION
  • 9.12. MOTOR HYDRAULIC
  • 9.13. HYDRAULIC CYLINDER ASSEMBLY S
  • 9.14. ROTARY DRIVE ASSEMBLY
  • 9.15. ROTARY DRIVE GEARBOX ASSEMBLY
  • 9.16. ROTARY DRIVE MOTOR HOSE KIT
  • 9.17. ROTARY DRIVE MOTOR FIELD KIT
  • 9.18. HYDRAULIC OPERATED BREAKOUT WRE
  • 9.19. HYDRAULIC CYLINDER ASSEMBLY C
  • 9.20. HYDRAULIC CYLINDER ASSEMBLY R
  • 9.21. HYDRAULIC OPERATED BREAKOUT WREW
  • 9.22. AUTOMATIC TOOL WRENCH
  • 9.23. HYDRAULIC CYLINDER ASSEMBLYB
  • 9.24. PIPE RACK ROTATE PLUMBING
  • 9.25. AUTO TOOL WRENCH PLUMBING
  • 9.26. PIPE RACK CAROUSEL LOCK PLUMBIN
  • 9.27. PIPE RACK SWING PLUMBING
  • 9.28. MAST LOCK INSTALLATION
  • 9.29. HYDRAULIC CYLINDER ASSEMBLY W M
  • 9.30. MAST LOCK INDICATOR HARNESS
  • 9.31. WINCH INSTALLATION BG8
  • 9.32. WINCH CASE DRAIN CONVERSION KIT
  • 9.33. WINCH ASSEMBLY
  • 9.34. SPRAG CLUTCH ASSEMBLY
  • 9.35. BRAKE VALVE ASSEMBLY WINCH
  • 9.36. PRIMARY PLANET CARRIER ASSEMBLY
  • 9.37. OUTPUT PLANET CARRIER ASSEMBLY
  • 9.38. MOTOR GROUP ASSEMBLY
  • 9.39. WINCH PLUMBING HOSE KIT
  • 10. SECT7.pdf
  • 10.1. SECTION 7 DRILLING TOOLS AC
  • 10.2. PIPE POSITIONER INSTALLATION
  • 10.3. PIPE POSITIONER PLUMBING COLD
  • 10.4. PIPE POSITIONER SENSOR COMPONEN
  • 10.5. MAST AUTO LUBE INJECTORS
  • 10.6. MAST AUTO LUBE HOSE KIT
  • 10.7. MAINFRAME AUTO LUBE INJECTORS
  • 10.8. MAINFRAME AUTO LUBE INJECTORS H
  • 10.9. SUB SHOCK FLOATING CUSHION
  • 10.10. GUIDE BUSHING INSTALLATION HAM
  • 10.11. RAPID FILL INSTALLATION
  • 10.12. CONNECTOR KIT RAPID FILL SYSTE
  • 10.13. RAPID FILL PLUMBING
  • 10.14. ROTARY TORQUE CONTROL INSTALLAT
  • 10.15. ROTARY TORQUE CONTROL PLUMBING
  • 10.16. OIL INJECTION INSTALLATION MD6
  • 10.17. AIR LINE LUBRICATOR TANK ASSEMB
  • 10.18. OIL INJECTION TANK 36 GAL
  • 10.19. AIR LINE LUBRICATOR HOSE KIT
  • 10.20. HARNESS AIR LINE LUBRICATOR
  • 10.21. HARNESS AIR LINE LUBRICATORD
  • 10.22. HARNESS AIR LINE LUBRICATOR
  • 10.23. AUTO LUBE ASSEMBLY MACHINE
  • 10.24. AUTO LUBE ASSEMBLY HOSE KIT
  • 10.25. HARNESS AUTO LUBE PRESSURE S
  • 10.26. PRESSURE SWITCH WITH WIRING
  • 10.27. FILTER REGULATOR LUBRICATOR
  • 10.28. WAY 2 POSITION SWITCH WITH WI
  • 10.29. AIR MOTOR ASSEMBLY MACHINE LUB
  • 10.30. HARNESS AUTO LUBE CONTROLLER
  • 10.31. TUBE ASSEMBLY AIR MOTOR MACHI
  • 10.32. MONITOR CONTROLLER MACHINE L
  • 10.33. LUBRICATOR INSTALLATION DRILL
  • 10.34. VALVE AIR
  • 10.35. LUBRICATOR ASSEMBLY DRILL STEM
  • 10.36. FILTER REGULATOR LUBRICATORT
  • 10.37. HARNESS THREAD LUBE SOLENOID
  • 10.38. LUBRICATOR HOSE PLUMBING KIT D
  • 11. SECT8.pdf
  • 11.1. SECTION 8 HYDRAULICS PLUMBI
  • 11.2. MAST LOCK PLUMBING
  • 11.3. AUXILIARY PUMP AND FEED VALVE P
  • 11.4. VALVE PLUMBING JACKS MAST
  • 11.5. MAST ELEVATING PLUMBING
  • 11.6. CHARGE HOSE PLUMBING
  • 11.7. SUCTION RETURN DRAIN PLUMBI
  • 11.8. HYDRAULIC FEED SYSTEM MODIFICAT
  • 11.9. HYDRAULIC FEED SYSTEM MODIFICATC
  • 11.10. HYDRAULIC RESERVOIR INSTALLATIO
  • 11.11. HYDRAULIC RESERVOIR SUBASSEMBLY
  • 11.12. OIL LEVEL SIGHT GAUGE
  • 11.13. FILTER ASSEMBLY MAIN RETURN
  • 11.14. FILTER ASSEMBLY CASE RETURN
  • 11.15. HYDRAULIC HAND PUMP ASSEMBLY
  • 11.16. TEST STATION MACHINE SYSTEM HY
  • 11.17. HOSE KIT HYDRAULIC TEST SYSTE
  • 11.18. JACK PLUMBING
  • 11.19. CLOSED LOOP PLUMBING W LOOP FIL
  • 11.20. FILTER ASSEMBLY LOOP
  • 11.21. LOOP FILTER PLUMBING
  • 11.22. HYDRAULIC VALVE PROXIMITY SWITC
  • 12. SECT9.pdf
  • 12.1. SECTION 9 ELECTRICAL
  • 12.2. ELECTRICAL SCHEMATIC LADDER LO
  • 12.3. MAINTENANCE FREE BATTERY KIT
  • 12.4. BATTERY ENGINE DISCONNECT INS
  • 12.5. BATTERY BOX ASSEMBLY
  • 12.6. HARNESS JUMPER BATTERY 16 I
  • 12.7. ADDITIONAL MAINTENANCE FREE BAT
  • 12.8. HEAD IS UP PIPE SENSOR
  • 12.9. HARNESS SENSOR HEAD IS UP
  • 12.10. TRAM INTERLOCK JACK
  • 12.11. HARNESS JACK INTERLOCK FRONT
  • 12.12. HARNESS JACK INTERLOCK FRONTq
  • 12.13. HARNESS JACK INTERLOCK REAR
  • 12.14. HARNESS JACK INTERLOCK REARP
  • 12.15. HARNESS JACK LIGHT INDICATORS
  • 12.16. TRAM INTERLOCK DRILL STEM
  • 12.17. HARNESS DRILL PIPE INTERLOCK
  • 12.18. PIPE RACK INTERLOCK
  • 12.19. HARNESS PIPE RACK INTERLOCK
  • 12.20. PIPE RACK INTERLOCK SWITCH W CO
  • 12.21. CLOSED CIRCUIT CAMERA SYSTEM
  • 12.22. REMOTE ENGINE START ASSEMBLY
  • 12.23. REMOTE ENGINE START CONTROL BOX
  • 12.24. HARNESS START STOP ENGINE
  • 12.25. ENGINE STOP KILL SWITCH GROU
  • 12.26. HARNESS GROUND LEVEL KILL
  • 12.27. SHUTDOWN TIMER KIT
  • 12.28. HARNESS SHUTDOWN TIMER
  • 12.29. SOUND SYSTEM INSTALLATION
  • 12.30. HARNESS RADIO
  • 12.31. ROTATING BEACON INSTALLATION
  • 12.32. BEACON ROTATING STROBE
  • 12.33. HARNESS BEACON MAST
  • 12.34. HARNESS BEACON FRONT
  • 12.35. HARNESS BEACON OPTION
  • 12.36. TACHOMETER INSTALLATION ROTARY
  • 12.37. ROTARY HEAD TAC HARNESS CAB
  • 12.38. ROTARY HEAD TAC HARNESS
  • 12.39. STANDARD LED LIGHT KIT
  • 12.40. EXTRA LED LIGHT KIT
  • 12.41. ADDITIONAL LIGHTS HARNESS LR
  • 12.42. ADDITIONAL LIGHTS HARNESS MAS
  • 12.43. HARNESS EXTRA LIGHT
  • 12.44. HARNESS EXTRA LIGHTS SWITCH
  • 12.45. FILTER INDICATOR INSTALLATION
  • 12.46. PRESSURE SWITCH W 3 PIN CONNECT
  • 12.47. PRESSURE SWITCH W 3 PIN CONNECTT
  • 12.48. PRESSURE SWITCH W 3 PIN CONNECTV
  • 12.49. HARNESS FILTER INDICATORS 1
  • 12.50. HARNESS FILTER INDICATORS 2
  • 12.51. CONVERTER KIT 24VDC TO 12VDC
  • 12.52. HARNESS CONVERTER CAT
  • 12.53. CAT EMS SYSTEM CAT ENGINE
  • 12.54. HARNESS CAT EMS CAT CUMMIN
  • 12.55. HARNESS EMS CAT ENGINE
  • 12.56. EXTERIOR HARNESS INSTALLATION
  • 12.57. HARNESS MAST OPTIONS 1
  • 12.58. HARNESS CAT CUMMINS ENGINE
  • 12.59. HARNESS VALVE MAST
  • 12.60. HARNESS CAB A C
  • 12.61. HARNESS A C CONDENSOR
  • 12.62. HARNESS VALVE BANKS LOWER
  • 12.63. HARNESS AUTO LUBE
  • 12.64. HARNESS TRAM
  • 12.65. HARNESS LIGHTS FRONT
  • 12.66. HARNESS VALVE MASTW
  • 12.67. HARNESS MAST 2
  • 12.68. CABLE GROUND CAB TO FRAME
  • 12.69. HARNESS JACK LEFT REAR
  • 12.70. HP BUTTERFLY COMPRESSOR COMPONE
  • 12.71. HARNESS COMPRESSOR 2 HIGH P
  • 12.72. INSTRUMENT PANEL ASSEMBLY W CAT
  • 12.73. INSTRUMENT PANEL SUBASSEMBLY W
  • 12.74. ELECTRIC HORN
Rate this product

Related products
