Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI006813

Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI006813 - Image 2

Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI006813 - Image 3

Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI006813

$30.00

Type Of Manual: Parts Manual
Manual ID: BI006813
Number of Pages: 677
Size: 24.6MB
Format: PDF

Category: Caterpillar Parts Manual PDF

Product details

Model List:
- MD6420 Rotary Blasthole Drill

1.
2. GENERAL ASSEMBLY ITEMS LIST
3. PARTS MANUAL SECTION LOCATOR
4. SECTION 1 DECALS FILTER ELE.pdf
4.1. SECTION 1 DECALS FILTER ELE
4.2. FILTER ELEMENTS
4.3. DECAL KIT MACHINE W WHITE CAB
4.4. DECAL KIT WARNING
5. SECTION 2 OPERATOR S CAB.pdf
5.1. SECTION 2 OPERATOR S CAB
5.2. CAB ASSEMBLY W GAUGES AND ATTAC
5.3. JUMPER SEAT WITH ATTACHING HARD
5.4. PANEL GAUGES ENGINE
5.5. PANEL GAUGES HYDRAULIC
5.6. PANEL SWITCHES DRILL FUNCTIO
5.7. CONTROL MAST JACKS
5.8. PANEL W ATTACHMENTS ENGINE STA
5.9. INSULATION KIT CAB SPECIAL
5.10. CAB HOSE PLUMBING
5.11. CAB MODIFICATION ELECTRIC HAND
5.12. ROTARY OPERATOR S SEAT
5.13. SEAT BELT W TETHER AND HARDWARE
5.14. GLASS INSTALLATION CAB TINTED
5.15. HEATER AIR CONDITIONER INSTAL
5.16. HEATER AIR CONDITIONER PACKAG
5.17. AIR CLEANER ASSEMBLY A C HEATE
5.18. CONDENSER 24V
5.19. WALL MOUNT UNIT W ANGLE LOUVERS
5.20. BLOWER ASSEMBLY A C HEATER PRE
5.21. HOSE KIT AIR CONDITIONER
5.22. WINDOW SHADE INSTALLATION OPER
5.23. SEAT AIR ACCUMULATOR INSTALLATI
5.24. WIPER WASHER INSTALLATION LE
5.25. WIPER WASHER ASSEMBLY OPERAT
5.26. WIPER WASHER INSTALLATION RE
5.27. WIPER WASHER INSTALLATION RI
6. SECTION 3 MAINFRAME CRAWLER.pdf
6.1. SECTION 3 MAINFRAME CRAWLER
6.2. MAINFRAME CRAWLER ASSEMBLY
6.3. UNDERCARRIAGE ASSEMBLY
6.4. FINAL DRIVE ASSEMBLY W MOTOR T
6.5. HYDRAULIC MOTOR SPARE PARTS
6.6. ROLLER ASSEMBLY TRACK
6.7. IDLER ASSEMBLY COMPLETE
6.8. TRACK ASSEMBLY W SHOES
6.9. ROCK GUARD COMPLETE FRONT AND
6.10. ROCK GUARD COMPLETE MIDDLE
6.11. MAST ELEVATING CYLINDER
6.12. DUST SEAL ASSEMBLY 30 DEG WI
6.13. FUEL TANK INSTALLATION 850 GA
6.14. JACK INSTALLATION
6.15. JACK CYLINDER ASSEMBLY 48 INCH
6.16. GRATING LH REAR JACK DECKING
6.17. TUBE LH AND REAR DECKING
6.18. VALVE STAND VALVES AND ATTACH
6.19. MANIFOLD W ATTACHMENTS RETURN
6.20. MANIFOLD W ATTACHMENTS DRAIN
6.21. VALVE JACKS MAST CONTROL WITH
6.22. VALVE ASSEMBLY JACKS MAST CONT
6.23. VALVE ASSEMBLY W ATTACHMENTS D
6.24. VALVE ASSEMBLY LESS ATTACHMENTS
6.25. VALVE ASSEMBLY W ATTACHMENTS F
6.26. VALVE ASSEMBLY LESS ATTACHMENTSx
6.27. VALVE ASSEMBLY W ATTACHMENTS C
6.28. VALVE ASSEMBLY LESS ATTACHMENTSxv
6.29. MANIFOLD W ATTACHMENTS
6.30. VALVE ASSEMBLY W ATTACHMENTS S
6.31. DIVERTER VALVE ASSEMBLY 2 POS
6.32. MANIFOLD PILOT CONTROL W ADAPT
6.33. MANIFOLD PILOT CONTROL W REGEN
6.34. MANIFOLD W ATTACHMENTS DRAIN
6.35. VALVE ASSEMBLY DUST COLLECTOR
6.36. VALVE ASSEMBLY DUST COLLECTORx
6.37. VALVE STAND VALVES HOSE PLUMBIN
6.38. VALVE STAND VALVES HOSE KIT
6.39. VIEWING HATCH DRILL DECK
6.40. HYDRAULIC CYLINDER ASSEMBLY
6.41. VIEWING HATCH PLUMBING
7. SECTION 4 ENGINES COMPRESSO.pdf
7.1. SECTION 4 ENGINES COMPRESSO
7.2. ENGINE WITH ATTACHMENT CAT C2
7.3. COUPLING PUMP DRIVE GEARBOX TO
7.4. DRIVELINE GUARD INSTALLATION
7.5. ENGINE PANEL STARTUP ASSEMBLY
7.6. FUEL FILTER INSTALLATION C27
7.7. FUEL FILTER
7.8. ENGINE PRELUBE INSTALLATION C
7.9. ENGINE PRELUBE PUMP
7.10. COOLANT CONDITIONER FILTER ASSE
7.11. ENGINE CHARGE PILOT PLUMBING
7.12. AIR CLEANER INSTALLATION ENGI
7.13. AIR CLEANER ASSEMBLY
7.14. ENGINE CHARGE AIR PIPING
7.15. ENGINE WATER PIPING INSTALLATIO
7.16. COOLER INSTALLATION COMPRESSOR
7.17. COOLER INSTALLATION COMPRESSORz
7.18. COOLER ASSEMBLY COMPRESSOR OIL
7.19. CHARGE AIR AFTERCOOLER ASSEMB
7.20. COOLER INSTALLATION ENGINE
7.21. ENGINE RADIATOR SYS HYDR OIL C
7.22. RADIATOR ASSEMBLY ENGINE
7.23. COOLER ASSEMBLY SYSTEM HYDRAUL
7.24. CHARGE AIR AFTERCOOLER ASSEMBx
7.25. MOTOR FAN
7.26. VALVE ASSEMBLY MOTOR CHECK
7.27. THERMOSTATIC VALVE ASSEMBLY
7.28. AIR CLEANER RAIN SHIELD ASSEMBL
7.29. AIR CLEANER INSTALLATION COMPR
7.30. COMPRESSOR AIR RECEIVER PIPING
7.31. MAIN AIR MANIFOLD ASSEMBLY
7.32. HYDRAULIC CYLINDER
7.33. COMPRESSOR AIR RECEIVER HOSE
7.34. AIR COMPRESSOR W ATTACHMENTS 2
7.35. AIR COMPRESSOR PACKAGE SERVICE
7.36. AIR COMPRESSOR PACKAGE PARTS LI
7.37. RECEIVER TANK ASSEMBLY COMPRES
7.38. COOLER ASSEMBLY
7.39. COOLER ASSEMBLY COMPRESSOR OILz
7.40. ENGINE RADIATOR
7.41. COOLER ASSEMBLY SYSTEM HYDRAULx
7.42. HYDRAULIC FILTER ASSEMBLY COMP
7.43. TORSIONAL DRIVE COUPLING
7.44. PUMP DRIVE ASSEMBLY
7.45. PUMP DRIVE GEARBOX 4 PAD
7.46. LINESHAFT ASSEMBLY INPUT GEAR
7.47. HIGH PRESSURE END FLANGE PLUGS
7.48. CONTROL ASSEMBLY
7.49. FILTER ELIMINATION BLOCK SPARE
7.50. CHARGE PILOT PUMP SPARE PARTS L
7.51. PUMP GEAR FAN
7.52. PUMP DUST COLLECTOR WATER INJE
7.53. MAIN PUMP OPEN LOOP
7.54. HYDRAULIC FILTER ASSEMBLY CHAR
7.55. HYDRAULIC CHARGE VALVE
7.56. MUFFLER ASSEMBLY
7.57. EXHAUST ELBOW GROUP LIST
7.58. AIR CLEANER RAIN SHIELD ASSEMBLz
8. SECTION 5 DUST CONTROL.pdf
8.1. SECTION 5 DUST CONTROL
8.2. DUST CURTAIN ASSEMBLY 30 DEG
8.3. DUST CURTAIN INSTALLATION
8.4. DUST CURTAIN HOSE PLUMBING
8.5. DUST CURTAIN ASSEMBLY FRONT
8.6. DUST CURTAIN HOSE PLUMBING FR
8.7. DUST COLLECTOR INSTALLATION
8.8. DUST COLLECTOR ASSEMBLY
8.9. AIR LINE FILTER REGULATOR DUST
8.10. DUST COLLECTOR PLUMBING
8.11. WATER INJECTION INSTALLATION 3
8.12. WATER PUMP ASSEMBLY
8.13. HYDRAULIC MOTOR
8.14. VALVE FLOW CONTROL
8.15. WATER INJECTION PLUMBING
9. SECTION 6 MAST.pdf
9.1. SECTION 6 MAST
9.2. MAST ASSEMBLY 13M W AUTO TENS
9.3. MAST PIVOT WELDMENT
9.4. HOIST AND PULLDOWN CYLINDER ASS
9.5. ROLLER ASSEMBLY CYLINDER GUIDE
9.6. CYLINDER AUTO FEED CABLE TENSI
9.7. CONTROL VALVE ASSEMBLY 9 STATI
9.8. CONTROL VALVE ASSEMBLY 9 STATIz
9.9. CLAMP HOIST AND PULLDOWN CYLIN
9.10. MAST HOSE PLUMBING
9.11. MANIFOLD TENSIONER
9.12. AUTO FEED CABLE TENSIONER PLUMB
9.13. AUTO TOOL WRENCH INSTALLATION
9.14. HOBO WRENCH INSTALLATION W O
9.15. HYDRAULIC OPERATED BREAKOUT WRE
9.16. HOSE KIT HYDRAULIC OPERATED B
9.17. CYLINDER 4 1 2 INCH BORE
9.18. CYLINDER 5 INCH BORE
9.19. CYLINDER 4 INCH BORE
9.20. WINCH INSTALLATION
9.21. WINCH CASE DRAIN CONVERSION KIT
9.22. WINCH ASSEMBLY
9.23. BRAKE VALVE ASSEMBLY WINCH
9.24. WINCH PLUMBING
9.25. MAST LOCK ASSEMBLY SLEEVED
9.26. PIPE POSITIONER PLUMBING
9.27. PIPE POSITIONER INSTALLATION
9.28. HYDRAULIC CYLINDER ASSEMBLY S
9.29. PIPE POSITIONER SENSOR COMPONEN
9.30. PIPE RACK INDEX PLUMBING
9.31. PIPE RACK LOCK PLUMBING
9.32. PIPE RACK SWING PLUMBING
9.33. PIPE RACK SWING INTERLOCK
9.34. PIPE RACK ASSEMBLY 40 FT 4 P
9.35. CYLINDER SWING PIPE RACK
9.36. CYLINDER INDEX PIPE RACK
9.37. MAST HOSE PLUMBINGz
9.38. MAST LOCK INDICATOR
9.39. MAST TUBING
9.40. ROTARY DRIVE ASSEMBLY
9.41. ROTARY DRIVE GEARCASE ASSEMBLY
9.42. MOTOR HYDRAULIC
9.43. SHUTTLE VALVE W TWO ORIFICES
9.44. FRONT MAST REST INSTALLATION
9.45. PIN RETAINER KIT MAST ELEVATI
9.46. PIN RETAINER KIT HOIST AND PU
10. SECTION 7 DRILLING TOOLS AC.pdf
10.1. SECTION 7 DRILLING TOOLS AC
10.2. RAPID FILL INSTALLATION 1100 G
10.3. CONNECTOR KIT RAPID FILL SYSTE
10.4. RAPID FILL PLUMBING
10.5. LUBE SYSTEM INSTALLATION MACHI
10.6. LUBRICATION SYSTEM MACHINE A
10.7. AIR MOTOR ASSEMBLY MACHINE LUB
10.8. TUBE ASSEMBLY AIR MOTOR MACHI
10.9. MONITOR CONTROLLER MACHINE L
10.10. FILTER REGULATOR LUBRICATOR
10.11. LUBRICATOR INSTALLATION DRILL
10.12. VALVE AIR
10.13. VALVE AIR part of 330617
10.14. VALVE AIR SOLENOID W JUNCTION
10.15. LUBRICATOR ASSEMBLY DRILL STEM
10.16. FILTER REGULATOR LUBRICATORz
10.17. LUBRICATOR HOSE PLUMBING KIT
10.18. AIR LINE LUBE KIT 35 GAL 350
10.19. AIR LINE LUBRICATOR TANK ASSEMB
10.20. OIL INJECTION TANK 36 GAL
10.21. AIR LINE LUBRICATOR HOSE KIT
10.22. ROTARY TORQUE CONTROL
10.23. ROTARY TORQUE CONTROL PLUMBING
10.24. HOSE COVER AND GRATING INSTALLA
10.25. DRILL PIPE GUIDE INSTALLATION
10.26. DRILL PIPE LOAD GUIDE
10.27. DRILLING EFFICIENCY INDICATOR I
10.28. DRILLING EFFICIENCY INDICATOR A
10.29. CHAIN DRIVE
10.30. SHOCK SUB 5 1 2 INCH API REG P
10.31. TACHOMETER INSTALLATION DIGITA
10.32. COLD WEATHER KIT INSTALLATION
10.33. HEATER COLD WEATHER KIT
10.34. HEATER ENGINE WATER PREHEAT KI
10.35. HEATER ASSEMBLY WATER PREHEAT
10.36. PUMP WATER HEATER PREHEAT KIT
10.37. SPARE PARTS KIT HEATER ENGINE
10.38. COLD WEATHER KIT PLUMBING
10.39. TRAM INTERLOCK JACK
10.40. TRAM INTERLOCK INSTALLATION 30
11. SECTION 8 HYDRAULICS PLUMBI.pdf
11.1. SECTION 8 HYDRAULICS PLUMBI
11.2. MAST ELEVATING PLUMBING
11.3. MAST LOCK PLUMBING
11.4. MAIN AIR PLUMBING
11.5. JACK PLUMBING
11.6. PROPEL PLUMBING
11.7. FAN PLUMBING COOLER
11.8. HYDRAULIC RESERVOIR INSTALLATIO
11.9. FILTER ASSEMBLY MAIN RETURN
11.10. FILTER ASSEMBLY CASE RETURN
11.11. FILTER INDICATOR WIRING
11.12. TEST STATION SYSTEM HYDRAULIC
11.13. TEST STATION SYSTEM HYDRAULIC x
11.14. TEST STATION SYSTEM HYDRAULICv
11.15. TEST STATION HYDRAULIC HOSE PLU
11.16. HYDRAULIC OPERATED BREAKOUT WREz
11.17. MANIFOLD ASSEMBLY W ATTACHMENTS
11.18. SUCTION PRESSURE RETURN PLUMB
11.19. CAB TO VALVE STAND PLUMBING
11.20. AUTO TOOL WRENCH PLUMBING
11.21. FIVE LOOP FILTER KIT
11.22. FILTER ASSEMBLY LOOP
12. SECTION 9 ELECTRICAL.pdf
12.1. SECTION 9 ELECTRICAL
12.2. WIRING DIAGRAM COMPONENTS
12.3. CAB WIRING HARNESS
12.4. ENGINE SKID CAB WIRING HARNES
12.5. CAB VALVE BANK WIRING HARNESS
12.6. MAST WIRING HARNESS
12.7. CAB DRILL PROPEL VALVE WIRING
12.8. ENGINE SKID ENGINE AIR COND
12.9. LIGHTS FRONT OF MACHINE WIRIN
12.10. DUST COLLECTOR TO ENGINE WIRING
12.11. BATTERY BOX ASSEMBLY
12.12. BATTERY ENGINE DISCONNECT INS
12.13. CONVERTER INSTALLATION 24 VDC
12.14. CONVERTER ELECTRONIC DC DC 1
12.15. ADDITIONAL LIGHTING KIT
12.16. REMOTE ENGINE START ASSEMBLY
12.17. EMERGENCY KILL SWITCH INSTALLAT
