Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI012745
Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI012745 - Image 2
Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI012745 - Image 3
Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI012745 - Image 4
Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI012745 - Image 5

Caterpillar MD6420 Rotary Blasthole Drill Parts Manual BI012745

$30.00

  • Type Of Manual: Parts Manual
  • Manual ID: BI012745
  • Number of Pages: 608
  • Size: 19.9MB
  • Format: PDF
Category:

Product details

  • Model List:

    • MD6420 Rotary Blasthole Drill
  • 1. SECT1.pdf
  • 1.1. SECTION 1 DECALS FILTER ELE
  • 1.2. FILTER ELEMENTS
  • 1.3. DECAL KIT CAT YELLOW MD6420
  • 1.4. DECAL KIT WARNING
  • 2. SECT2.pdf
  • 2.1. SECTION 2 OPERATOR S CAB
  • 2.2. CAB ASSEMBLY W ELECTRIC CONTROL
  • 2.3. CAB WINDOW WIPER WASHER INSTALL
  • 2.4. WINDSHIELD WIPER SYSTEM 24 IN
  • 2.5. HARNESS WINDOW WIPER RIGHT S
  • 2.6. HARNESS WINDOW WIPER LEFT SI
  • 2.7. HARNESS WINDOW WIPER FRONT T
  • 2.8. JUMPER SEAT WITH ATTACHING HARD
  • 2.9. PANEL GAUGES ENGINE
  • 2.10. PANEL GAUGES HYDRAULIC
  • 2.11. PANEL SWITCHES DRILL FUNCTIO
  • 2.12. CONTROL MAST JACKS
  • 2.13. PANEL W ATTACHMENTS ENGINE STA
  • 2.14. INSULATION KIT CAB SPECIAL
  • 2.15. CAB PLUMBING
  • 2.16. CAB MODIFICATION ELECTRIC HAND
  • 2.17. SEAT AIR ACCUMULATOR INSTALLATI
  • 2.18. GLASS INSTALLATION CAB TINTED
  • 2.19. ROTARY OPERATOR S SEAT
  • 2.20. SEAT BELT W TETHER AND HARDWARE
  • 2.21. HEATER AIR CONDITIONER INSTAL
  • 2.22. HEATER AIR CONDITIONER PACKAG
  • 2.23. AIR CLEANER ASSEMBLY A C HEATE
  • 2.24. CONDENSER 24V
  • 2.25. WALL MOUNT UNIT W ANGLE LOUVERS
  • 2.26. BLOWER ASSEMBLY A C HEATER PRE
  • 2.27. AIR CONDITIONER HOSE KIT
  • 2.28. HARNESS CIRCUIT BREAKER A C
  • 2.29. WINDOW SHADE INSTALLATION OPER
  • 3. SECT3.pdf
  • 3.1. SECTION 3 MAINFRAME CRAWLER
  • 3.2. MAINFRAME CRAWLER ASSEMBLY C
  • 3.3. MAST ELEVATING CYLINDER ASSEMBL
  • 3.4. PROPEL PLUMBING
  • 3.5. DUST SEAL ASSEMBLY 30 DEG WI
  • 3.6. COUNTERBALANCE VALVE ASSEMBLY W
  • 3.7. FUEL TANK INSTALLATION 850 GA
  • 3.8. JACK INSTALLATION
  • 3.9. JACK CYLINDER ASSEMBLY 48 INCH
  • 3.10. VIEWING HATCH DRILL DECK
  • 3.11. HYDRAULIC CYLINDER ASSEMBLY
  • 3.12. VIEWING HATCH PLUMBING
  • 4. SECT4.pdf
  • 4.1. SECTION 4 ENGINES COMPRESSO
  • 4.2. ENGINE WITH ATTACHMENT CAT C2
  • 4.3. COUPLING PUMP DRIVE GEARBOX TO
  • 4.4. DRIVELINE GUARD INSTALLATION
  • 4.5. ENGINE PANEL STARTUP ASSEMBLY
  • 4.6. FUEL FILTER INSTALLATION C27
  • 4.7. FUEL FILTER
  • 4.8. ENGINE PRELUBE INSTALLATION C
  • 4.9. ENGINE PRELUBE PUMP
  • 4.10. COOLANT CONDITIONER FILTER ASSE
  • 4.11. ENGINE CHARGE PILOT PLUMBING
  • 4.12. AIR CLEANER PIPING ENGINE
  • 4.13. AIR CLEANER ASSEMBLY
  • 4.14. ENGINE WATER PIPING
  • 4.15. PUMP DRIVE ASSEMBLY
  • 4.16. PUMP DRIVE GEARBOX 4 PAD
  • 4.17. LINESHAFT ASSEMBLY INPUT GEAR
  • 4.18. PUMP GEAR FAN
  • 4.19. PUMP GEAR DOUBLE
  • 4.20. HYDRAULIC CHARGE VALVE
  • 4.21. AIR CLEANER RAIN SHIELD ASSEMBL
  • 4.22. AIR CLEANER PIPING COMPRESSOR
  • 4.23. MUFFLER INSTALLATION ENGINE
  • 4.24. EXHAUST ELBOW GROUP LIST
  • 4.25. COMPRESSOR AIR RECEIVER PIPING
  • 4.26. MAIN AIR MANIFOLD ASSEMBLY
  • 4.27. HYDRAULIC CYLINDER
  • 4.28. HYDRAULIC FILTER ASSEMBLY COMP
  • 4.29. COMPRESSOR AIR RECEIVER PIPINGx
  • 4.30. AIR COMPRESSOR WITH ATTACHMENTS
  • 4.31. AIR COMPRESSOR PACKAGE SERVICE
  • 4.32. COMPRESSOR AIR END ATTACHMENTS
  • 4.33. RECEIVER TANK ASSEMBLY
  • 4.34. REGULATOR CONTROL PANEL ASSEMBL
  • 4.35. DISCHARGE ASSEMBLY
  • 4.36. TORSIONAL DRIVE COUPLING
  • 4.37. COOLER INSTALLATION
  • 4.38. COOLER ASSEMBLY W PLUMBING ENG
  • 4.39. OIL COOLER ASSEMBLY COMPRESSOR
  • 4.40. RADIATOR ASSEMBLY
  • 4.41. CHARGE AIR AFTERCOOLER ASSEMB
  • 4.42. COOLER ASSEMBLY HYDRAULIC OIL
  • 4.43. MOTOR FAN
  • 4.44. THERMOSTATIC VALVE ASSEMBLY
  • 5. SECT5.pdf
  • 5.1. SECTION 5 DUST CONTROL
  • 5.2. DUST CURTAIN ASSEMBLY 30 DEG
  • 5.3. DUST CURTAIN INSTALLATION
  • 5.4. DUST CURTAIN HOSE PLUMBING
  • 5.5. WATER INJECTION SYSTEM
  • 5.6. WATER PUMP ASSEMBLY
  • 5.7. POWER END ASSEMBLY RH
  • 5.8. HYDRAULIC MOTOR
  • 5.9. WATER TANK 600 GALLON
  • 5.10. VALVE FLOW CONTROL
  • 5.11. WATER INJECTION HOSE PLUMBING
  • 5.12. DUST CURTAIN ASSEMBLY FRONT
  • 5.13. DUST CURTAIN HOSE PLUMBING FR
  • 6. SECT6.pdf
  • 6.1. SECTION 6 MAST
  • 6.2. MAST ASSEMBLY 35 FT 30 DEG WI
  • 6.3. MAST PIVOT WELDMENT
  • 6.4. HOIST PULLDOWN CYLINDER ASSEMBL
  • 6.5. MAST PLUMBING W HOLDBACK
  • 6.6. AUTO TOOL WRENCH INSTALLATION
  • 6.7. HOBO WRENCH INSTALLATION W O
  • 6.8. HYDRAULIC OPERATED BREAKOUT WRE
  • 6.9. HOSE KIT HYDRAULIC OPERATED B
  • 6.10. CYLINDER 4 1 2 INCH BORE SWIN
  • 6.11. CYLINDER 5 INCH BORE ROTATE T
  • 6.12. CYLINDER 4 INCH BORE CLAMP
  • 6.13. MAST LOCK ASSEMBLY SLEEVED
  • 6.14. AUTOMATIC PIPE POSITIONER SENSO
  • 6.15. PIPE POSITIONER INSTALLATION
  • 6.16. HYDRAULIC CYLINDER ASSEMBLY S
  • 6.17. PIPE POSITIONER SENSOR COMPONEN
  • 6.18. PIPE RACK ASSEMBLY MD6420
  • 6.19. CYLINDER SWING PIPE RACK
  • 6.20. CYLINDER INDEX PIPE RACK
  • 6.21. MAST HOSE PLUMBING
  • 6.22. AUTO TOOL WRENCH PLUMBING
  • 6.23. PIPE POSITIONER PLUMBING
  • 6.24. PIPE RACK SWING PLUMBING
  • 6.25. PIPE RACK ROTATE PLUMBING
  • 6.26. PIPE RACK LOCK PLUMBING
  • 6.27. WINCH PLUMBING
  • 6.28. ROTARY DRIVE ASSEMBLY
  • 6.29. ROTARY DRIVE GEARCASE ASSEMBLY
  • 6.30. MOTOR HYDRAULIC
  • 6.31. SHUTTLE VALVE W TWO ORIFICES
  • 6.32. WINCH INSTALLATION
  • 6.33. WINCH CASE DRAIN CONVERSION KIT
  • 6.34. WINCH ASSEMBLY
  • 6.35. BRAKE VALVE ASSEMBLY WINCH
  • 6.36. MAST LOCK INDICATOR
  • 6.37. PIPE RACK SWING INTERLOCK
  • 7. SECT7.pdf
  • 7.1. SECTION 7 DRILLING TOOLS AC
  • 7.2. RAPID FILL INSTALLATION
  • 7.3. CONNECTOR KIT RAPID FILL SYSTE
  • 7.4. RAPID FILL PLUMBING
  • 7.5. LUBE SYSTEM INSTALLATION MACHI
  • 7.6. LUBRICATION SYSTEM MACHINE A
  • 7.7. AIR MOTOR ASSEMBLY MACHINE LUB
  • 7.8. TUBE ASSEMBLY AIR MOTOR MACHI
  • 7.9. MONITOR CONTROLLER MACHINE L
  • 7.10. FILTER REGULATOR LUBRICATOR
  • 7.11. LUBRICATOR INSTALLATION DRILL
  • 7.12. VALVE AIR
  • 7.13. LUBRICATOR ASSEMBLY DRILL STEM
  • 7.14. FILTER REGULATOR LUBRICATORs
  • 7.15. LUBRICATOR HOSE PLUMBING KIT
  • 7.16. DRILL PIPE GUIDE INSTALLATION
  • 7.17. DRILL PIPE LOAD GUIDE
  • 7.18. ROTARY TORQUE CONTROL INSTALLAT
  • 7.19. ROTARY TORQUE CONTROL PLUMBING
  • 7.20. FLUSHING VALVE INSTALLATION
  • 7.21. LOOP STRIPPING VALVE
  • 7.22. OIL INJECTION INSTALLATION
  • 7.23. AIR LINE LUBRICATOR TANK ASSEMB
  • 7.24. OIL INJECTION TANK 36 GAL
  • 7.25. HARNESS AIR LINE LUBRICATOR
  • 7.26. AIR LINE LUBRICATOR HOSE KIT
  • 7.27. HARNESS AIR LINE LUBRICATOR
  • 7.28. HARNESS AIR LINE LUBRICATOR s
  • 7.29. TRAM INTERLOCK INSTALLATION 30
  • 7.30. TACHOMETER INSTALLATION DIGITA
  • 7.31. SHOCK SUB 5 1 2 INCH API REG P
  • 7.32. BLOWDOWN HOSE ASSEMBLY
  • 7.33. GUIDE BUSHING ASSEMBLY SPECIA
  • 7.34. REMOTE TRAM INSTALLATION
  • 7.35. HARNESS WIRING PENDANT TETHE
  • 8. SECT8.pdf
  • 8.1. SECTION 8 HYDRAULICS PLUMBI
  • 8.2. MAST ELEVATING PLUMBING
  • 8.3. MAST LOCK PLUMBING
  • 8.4. MAIN AIR PLUMBING
  • 8.5. JACK PLUMBING HOSE KIT
  • 8.6. FAN PLUMBING COOLER
  • 8.7. HYDRAULIC TANK ASSEMBLY 250 G
  • 8.8. CONTROL VALVE ASSEMBLY 4 SECTI
  • 8.9. FILTER ASSEMBLY MAIN RETURN
  • 8.10. FILTER ASSEMBLY CASE RETURN
  • 8.11. CONTROL VALVE ASSEMBLY 6 SECTI
  • 8.12. SUCTION AND RETURN PLUMBING
  • 8.13. LOOP FILTER ASSEMBLY W PLUMBING
  • 8.14. LOOP FILTER PLUMBING
  • 8.15. FILTER ASSEMBLY HIGH FATIGUE
  • 8.16. PILOT PLUMBING W CHARGE RETUR
  • 8.17. HOSE KIT CHARGE AND PILOT PLU
  • 8.18. CHARGE PLUMBING KIT RH CHARGE
  • 8.19. PILOT PLUMBING LH CHARGE
  • 8.20. FILTER VALVES AND ATTACHMENTS
  • 8.21. CONTROL VALVE ASSEMBLY 8 SECTI
  • 8.22. HYDRAULIC FILTER ASSEMBLY CHAR
  • 8.23. DIVERTER VALVE ASSEMBLY 2 POS
  • 8.24. HYDRAULIC HAND PUMP INSTALLATIO
  • 8.25. HYDRAULIC HAND PUMP ASSEMBLY
  • 8.26. HYDRAULIC TEST SYSTEM
  • 8.27. TEST STATION SYSTEM HYDRAULIC
  • 8.28. ENGINE CHARGE AIR PIPING
  • 9. SECT9.pdf
  • 9.1. SECTION 9 ELECTRICAL
  • 9.2. WIRING DIAGRAMS COMPONENTS
  • 9.3. CAB WIRING HARNESS COLD WEATHE
  • 9.4. ENGINE SKID CAB WIRING HARNESS
  • 9.5. CAB VALVE BANK WIRING HARNESS
  • 9.6. MAST WIRING HARNESS
  • 9.7. CAB DRILL PROPEL VALVE WIRING
  • 9.8. ENGINE SKID ENGINE AIR COND
  • 9.9. LIGHTS FRONT OF MACHINE WIRIN
  • 9.10. DUST COLLECTOR TO ENGINE WIRING
  • 9.11. BATTERY BOX ASSEMBLY
  • 9.12. BATTERY ENGINE DISCONNECT INS
  • 9.13. FILTER INDICATOR WIRING CLOS
  • 9.14. ENGINE STOP KILL SWITCH INSTALL
  • 9.15. ELECTRIC HORN
  • 9.16. HARNESS HORN PUSHBUTTON
  • 9.17. REMOTE ENGINE START ASSEMBLY
  • 9.18. REMOTE ENGINE START CONTROL BOX
  • 9.19. HARNESS START STOP ENGINE
  • 9.20. STANDARD LED LIGHT KIT
  • 9.21. ADDITIONAL LED LIGHT KIT
  • 9.22. SOUND SYSTEM INSTALLATION
  • 9.23. TRAM INTERLOCK JACK
  • 9.24. HARNESS JACK INTERLOCK FRONT
  • 9.25. HARNESS JACK INTERLOCK FRONTz
  • 9.26. HARNESS JACK INTERLOCK REAR
  • 9.27. HARNESS JACK INTERLOCK REAR z
  • 9.28. HARNESS JACK LIGHT INDICATORS
  • 9.29. CLOSED CIRCUIT CAMERA SYSTEM
