Caterpillar MD6420B Rotary Blasthole Drill Parts Manual BI006806
Caterpillar MD6420B Rotary Blasthole Drill Parts Manual BI006806 - Image 2
Caterpillar MD6420B Rotary Blasthole Drill Parts Manual BI006806 - Image 3
Caterpillar MD6420B Rotary Blasthole Drill Parts Manual BI006806 - Image 4
Caterpillar MD6420B Rotary Blasthole Drill Parts Manual BI006806 - Image 5

Caterpillar MD6420B Rotary Blasthole Drill Parts Manual BI006806

$30.00

  • Type Of Manual: Parts Manual
  • Manual ID: BI006806
  • Number of Pages: 1050
  • Size: 28.2MB
  • Format: PDF
Category:

Product details

  • Model List:

    • MD6420B Rotary Blasthole Drill
  • 1. Binder1
  • 1.1. PARTS MANUAL SECTION LOCATOR
  • 1.2. GENERAL ASSEMBLY ITEMS LIST
  • 1.3. SECTION 1 DECALS FILTER ELE
  • 1.4. DECAL KIT MACHINE CAT YELLOW
  • 1.5. DECAL KIT WARNING
  • 1.6. FILTER ELEMENTS
  • 2. Binder2
  • 2.1. SECTION 2 OPERATOR S CAB
  • 2.2. CAB INSTALLATION
  • 2.3. CAB ASSEMBLY
  • 2.4. ROTARY OPERATOR S SEAT
  • 2.5. SEAT BELT W TETHER AND HARDWARE
  • 2.6. CAB ELECTRICAL SUB ASSEMBLY
  • 2.7. CAB JUNCTION PANEL ELECTRICAL A
  • 2.8. CAB MODULE PANEL ELECTRICAL ASS
  • 2.9. CONNECTOR ASSEMBLY CONTROL MO
  • 2.10. CONNECTOR ASSEMBLY CONTROL MO 1
  • 2.11. CAB SUB ASSEMBLY
  • 2.12. KIT CAB GLASS
  • 2.13. CAB SEAT AIR ACCUMULATOR INSTAL
  • 2.14. CONSOLE ASSEMBLY
  • 2.15. CONTROL PANEL LH LOWER SIDE
  • 2.16. CONSOLE ASSEMBLY RH LOWER
  • 2.17. CONTROL PANEL RH UPPER SIDE
  • 2.18. CIRCUIT BREAKER PANEL ASSEMBLY
  • 2.19. WINDSHIELD WIPER INSTALLATION
  • 2.20. WINDOW SHADE INSTALLATION
  • 2.21. ELECTRICAL HARNESS INSTALLATION
  • 2.22. INSTALLATION HVAC UNIT
  • 2.23. HVAC ASSEMBLY 24VDC
  • 2.24. RETURN AIR ASSEMBLY
  • 2.25. SUPPLY AIR PLENUM ASSEMBLY
  • 2.26. HVAC ASSEMBLY 24VDC 8KW
  • 2.27. KIT M8 HYD DRIVEN COMPRESSOR
  • 2.28. SPARE PARTS LIST ELECTRICAL P
  • 2.29. INTERFACE MINING SYSTEM
  • 3. Binder3
  • 3.1. SECTION 3 MAINFRAME CRAWLER
  • 3.2. MAINFRAME CRAWLER ASSEMBLY
  • 3.3. UNDERCARRIAGE ASSEMBLY
  • 3.4. FINAL DRIVE ASSEMBLY W MOTOR T
  • 3.5. HYDRAULIC MOTOR SPARE PARTS
  • 3.6. IDLER ASSEMBLY COMPLETE
  • 3.7. TRACK ASSEMBLY W SHOES
  • 3.8. ROCK GUARD COMPLETE FRONT AND
  • 3.9. ROCK GUARD COMPLETE MIDDLE
  • 3.10. FUEL TANK INSTALLATION 850 GA
  • 3.11. JACK INSTALLATION
  • 3.12. JACK ASSEMBLY 48 INCH
  • 3.13. JACK CYLINDER ASSEMBLY 48 INCH
  • 3.14. JACK ASSEMBLY 48 INCH 1
  • 3.15. HYDRAULIC CASCADING STAIRS INST
  • 3.16. HYDRAULIC FOLDING STAIRWAY ASSE
  • 3.17. FOLDING STAIRWAY ASSEMBLY
  • 3.18. LADDER CONTROL BOX ASSEMBLY
  • 3.19. INSTALLATION HYDRAULIC CASCAD
  • 3.20. SOLENOID VALVE ASSEMBLY 24VDC
  • 3.21. ENGINE ACCESS WALKWAYS BOLT O
  • 3.22. SWING GATE ASSEMBLY
  • 3.23. MAST REST FRONT
  • 3.24. WASHDOWN PUMP ASSEMBLY
  • 3.25. PRESSURE WASHER PUMP ASSEMBLY
  • 3.26. PRESSURE WASHER BOX
  • 3.27. HOSE REEL INSTALLATION WASHDO
  • 3.28. HOSE REEL WASHDOWN PUMP
  • 3.29. ANGLE DRILL KIT HOOD SEALS
  • 3.30. DUST SEALS INSTALLATION 20DEG
  • 3.31. SLIDING VIEWING HATCH INSTALLAT
  • 3.32. SLIDING VIEWING HATCH ASSEMBLY
  • 3.33. PLUMBING INSTALLATION SLIDING
  • 3.34. HOSE KIT VIEWING HATCH
  • 3.35. DRILL DECK HANDRAIL INSTALLATIO
  • 3.36. SWING GATE ASSEMBLY 1
  • 4. Binder4
  • 4.1. SECTION 4 ENGINES COMPRESSO
  • 4.2. ENGINE W ATTACHMENTS CUMMINS Q
  • 4.3. DRIVE COUPLING
  • 4.4. COUPLING GUARD ASSEMBLY
  • 4.5. HOSE KIT ENGINE
  • 4.6. AIR CLEANER INSTALLATION ENGIN
  • 4.7. AIR CLEANER ASSEMBLY
  • 4.8. ENGINE WATER PIPING
  • 4.9. ENGINE COOLER INSTALLATION
  • 4.10. ENGINE COOLER ASSEMBLY
  • 4.11. COOLER ASSEMBLY
  • 4.12. ENGINE RADIATOR ASSEMBLY
  • 4.13. COOLER ASSEMBLY SYSTEM HYDRAUL
  • 4.14. MOTOR FAN
  • 4.15. VALVE ASSEMBLY MOTOR CHECK
  • 4.16. THERMOSTATIC VALVE ASSEMBLY
  • 4.17. COMPRESSOR COOLER INSTALLATION
  • 4.18. COMPRESSOR COOLER ASSEMBLY
  • 4.19. REGULATOR PANEL ASSEMBLY SPARE
  • 4.20. COMPRESSOR COOLER ASSEMBLY 1
  • 4.21. OIL COOLER
  • 4.22. ALTERNATOR W BELT SHEAVE
  • 4.23. AIR CLEANER INSTALLATION COMPR
  • 4.24. COMPRESSOR AIR RECEIVER PIPING
  • 4.25. HYDRAULIC FILTER ASSEMBLY COMP
  • 4.26. HOSE KIT RECEIVER PIPING
  • 4.27. PNEUMATIC AIR SCHEMATIC
  • 4.28. AIR COMPRESSOR INSTALLATION
  • 4.29. AIR COMPRESSOR ASSEMBLY SPARE P
  • 4.30. AIR COMPRESSOR SPARE PARTS LIST
  • 4.31. DISCHARGE SYSTEM ASSEMBLY SPARE
  • 4.32. AIR COMPRESSOR RECEIVER TANK AS
  • 4.33. TORSIONAL DRIVE COUPLING
  • 4.34. PUMP DRIVE ASSEMBLY STRAIGHT
  • 4.35. PUMP DRIVE GEARBOX 4 PAD
  • 4.36. LINESHAFT ASSEMBLY INPUT GEAR
  • 4.37. PUMP AXIAL PISTON LOAD SENSE
  • 4.38. VARIABLE DISPLACEMENT PUMP
  • 4.39. SHAFT SEAL AND CASE DRAIN PLUG
  • 4.40. HIGH PRESSURE END FLANGE PLUGS
  • 4.41. FILTER ELIMINATION BLOCK SPARE
  • 4.42. CONTROL ASSEMBLY
  • 4.43. CHARGE PILOT PUMP SPARE PARTS L
  • 4.44. PUMP GEAR FAN
  • 4.45. ENGINE MUFFLER INSTALLATION
  • 4.46. MAIN AIR PLUMBING INSTALLATION
  • 4.47. MAIN AIR LINE ASSEMBLY ENGINE
  • 4.48. HOSE KIT MAIN AIR PLUMBING
  • 4.49. MAIN AIR MANIFOLD ASSEMBLY
  • 4.50. COMPRESSOR CONTROL PIPING
  • 4.51. HOSE KIT COMPRESSOR CONTROL P
  • 4.52. PLUMBING INSTALLATION AUXILIA
  • 4.53. EXHAUST BLANKET ASSEMBLY
  • 5. Binder5
  • 5.1. SECTION 5 DUST CONTROL
  • 5.2. DUST CURTAIN INSTALLATION
  • 5.3. FRONT DUST SKIRT LIFTER INSTALL
  • 5.4. FRONT SKIRT LIFTER ASSEMBLY B
  • 5.5. DUST CURTAIN LIFTER ASSEMBLY
  • 5.6. HYDRAULIC CYLINDER ASSEMBLY
  • 5.7. WATER INJECTION INSTALLATION 3
  • 5.8. WATER TANK ASSEMBLY RH
  • 5.9. WATER TANK ASSEMBLY LH
  • 5.10. WATER PUMP GUARD MOUNTING
  • 5.11. WATER PUMP ASSEMBLY
  • 5.12. POWER END ASSEMBLY RH
  • 5.13. HYDRAULIC MOTOR
  • 5.14. INSTALLATION REAR DUST SKIRT
  • 5.15. DUST CURTAIN LIFTER ASSEMBLY 1
  • 5.16. WATER PIPING WATER INJECTION
  • 5.17. HOSE KIT WATER INJECTION WA
  • 5.18. PLUMBING INSTALLATION WATER I
  • 5.19. HOSE KIT WATER INJECTION
  • 6. Binder6
  • 6.1. SECTION 6 MAST
  • 6.2. MAST ASSEMBLY 50 FT
  • 6.3. MAST PIVOT TRUNNION BLOCK
  • 6.4. DRILL PIPE CATCHER ASSEMBLY INS
  • 6.5. HYDRAULIC CYLINDER ASSEMBLY S
  • 6.6. CYLINDER HOIST PULLDOWN MAST
  • 6.7. COUNTERBALANCE VALVE HOIST PU
  • 6.8. CYLINDER AUTO FEED CABLE TENSI
  • 6.9. MAST CONTROL VALVE 9 BANK
  • 6.10. MAST SUPPORT ASSEMBLY
  • 6.11. MAST RAISE CYLINDER INSTALLATIO
  • 6.12. CYLINDER ASSEMBLY MAST RAISE
  • 6.13. HOBO WRENCH INSTALLATION TELE
  • 6.14. CYLINDER 4 1 2 INCH BORE
  • 6.15. CYLINDER 5 INCH BORE
  • 6.16. CYLINDER 4 INCH BORE
  • 6.17. DECK WRENCH W HYDRAULIC OPERATE
  • 6.18. CYLINDER
  • 6.19. WINCH INSTALLATION W O CABLE
  • 6.20. WINCH ASSEMBLY
  • 6.21. SPRAG CLUTCH ASSEMBLY
  • 6.22. PRIMARY PLANET CARRIER ASSEMBLY
  • 6.23. OUTPUT PLANET CARRIER ASSEMBLY
  • 6.24. BRAKE CYLINDER ASSEMBLY
  • 6.25. MOTOR GROUP ASSEMBLY
  • 6.26. BRAKE VALVE ASSEMBLY WINCH
  • 6.27. MAST LOCK INSTALLATION SLEEVE
  • 6.28. HYDRAULIC CYLINDER
  • 6.29. MAST PIPE POSITIONER INSTALLATI
  • 6.30. PIPE POSITIONER SWING ARM ASSEM
  • 6.31. PIPE RACK INSTALLATION
  • 6.32. CYLINDER HYDRAULIC
  • 6.33. CYLINDER INDEX PIPE RACK
  • 6.34. PROXIMITY SWITCH INSTALLATION
  • 6.35. ROTARY DRIVE ASSEMBLY
  • 6.36. ROTARY DRIVE GEARCASE ASSEMBLY
  • 6.37. MOTOR HYDRAULIC
  • 6.38. SHUTTLE VALVE W TWO ORIFICES
  • 6.39. MAST ANGLE INSTALLATION
  • 6.40. MAST ACCESS ASSEMBLY INSTALLATI
  • 6.41. MAST ACCESS ASSEMBLY
  • 6.42. MAST ACCESS GATE ASSEMBLY
  • 6.43. LINEAR TRANSDUCER HEAD POSITION
  • 6.44. MAGNET ASSEMBLY LINEAR TRANSD
  • 7. Binder7
  • 7.1. SECTION 7 DRILLING TOOLS AC
  • 7.2. RAPID FILL INSTALLATION
  • 7.3. RAPID FILL BOX ASSEMBLY
  • 7.4. CENTRAL LUBE TANK INSTALLATION
  • 7.5. CENTRAL LUBE TANK ASSEMBLY
  • 7.6. PUMP ASSEMBLY
  • 7.7. PLUMBING INSTALLATION CENTRAL
  • 7.8. HOSE KIT CENTRAL LUBE PUMP
  • 7.9. LUBRICATOR INSTALLATION DRILL
  • 7.10. FILTER REGULATOR LUBRICATOR
  • 7.11. THREAD LUBE ASSEMBLY
  • 7.12. LUBRICATOR ASSEMBLY DRILL STEM
  • 7.13. ADJUSTABLE GREASER SPRAY HOLDER
  • 7.14. LIMIT SWITCH INSTALLATION TRA
  • 7.15. FIRE SUPPRESSION SYSTEM INSTALL
  • 7.16. TRAM BEACON INSTALLATION
  • 7.17. LIVE SAMPLING STATION ASSEMBLY
  • 7.18. HOSE KIT LIVE SAMPLING STATIO
  • 7.19. LIVE SAMPLING STATION ENCLOSURE
  • 7.20. ENTERTAINMENT RADIO INSTALLATIO
  • 7.21. CONVERTER ELECTRONIC DC DC 1
  • 7.22. HORN INSTALLATION
  • 7.23. STANDARD ASSEMBLY GROUP
  • 7.24. MAST SAFETY LANYARD W O CABLE
  • 8. Binder8
  • 8.1. SECTION 8 HYDRAULICS PLUMBI
  • 8.2. PLUMBING INSTALLATION MAIN PU
  • 8.3. HOSE KIT MAIN PUMP
  • 8.4. HYDRAULIC CHARGE VALVE
  • 8.5. CHARGE OIL FILTER ASSEMBLY INST
  • 8.6. HYDRAULIC FILTER ASSEMBLY CHAR
  • 8.7. LOOP FILTER ASSEMBLY KIT
  • 8.8. FILTER ASSEMBLY LOOP
  • 8.9. HYDRAULIC TANK INSTALLATION
  • 8.10. HYDRAULIC TANK ASSEMBLY
  • 8.11. FILTER ASSEMBLY MAIN RETURN
  • 8.12. FILTER ASSEMBLY CASE RETURN
  • 8.13. RESERVE OIL TANK INSTALLATION
  • 8.14. OIL RESERVE TANK ASSEMBLY
  • 8.15. PLUMBING INSTALLATION PIPE CA
  • 8.16. HOSE KIT PIPE CATCHER
  • 8.17. PLUMBING INSTALLATION CENTRAL
  • 8.18. HOSE KIT CENTRAL LUBE MAINFR
  • 8.19. PLUMBING INSTALLATION CENTRAL 1
  • 8.20. HOSE KIT CENTRAL LUBE MAST
  • 8.21. PLUMBING INSTALLATION WATER I
  • 8.22. HOSE KIT WATER PUMP INJECTION
  • 8.23. PIPING INSTALLATION WATER WAS
  • 8.24. HOSE KIT WATER WASHDOWN PLUMB
  • 8.25. PLUMBING INSTALLATION FUEL FI
  • 8.26. HOSE KIT FUEL FILL
  • 8.27. PLUMBING INSTALLATION MAST HO
  • 8.28. HOSE KIT MAST HOBO FUNCTIONS
  • 8.29. PLUMBING INSTALLATION MAST RA
  • 8.30. HOSE KIT MAST RAISE
  • 8.31. PLUMBING INSTALLATION PIPE PO
  • 8.32. HOSE KIT PIPE POSTIONER PLUMB
  • 8.33. PLUMBING INSTALLATION FAN CIR
  • 8.34. HOSE KIT FAN CIRCUIT
  • 8.35. HIGH PRESSURE VALVE MANIFOLD
  • 8.36. PLUMBING INSTALLATION REAR JA
  • 8.37. HOSE KIT REAR JACK PLUMBING
  • 8.38. PLUMBING KIT FRONT JACKS
  • 8.39. HOSE KIT FRONT JACKS
  • 8.40. PLUMBING INSTALLATION MAST LO
  • 8.41. HOSE KIT MAST LOCK
  • 8.42. PLUMBING INSTALLATION THREAD
  • 8.43. HOSE KIT THREAD LUBE MAINFRA
  • 8.44. PLUMBING INSTALLATION THREAD
  • 8.45. HOSE KIT THREAD LUBE MAST
  • 8.46. PLUMBING INSTALLATION MAST PI
  • 8.47. HOSE KIT MAST PIPE RACK FUNCT
  • 8.48. PLUMBING INSTALLATION TRAM
  • 8.49. HOSE KIT TRAM
  • 8.50. LOOP STRIPPING VALVE
  • 8.51. PLUMBING INSTALLATION MAST TH
  • 8.52. HOSE KIT MAST DECK WRENCH HOB
  • 8.53. PLUMBING INSTALLATION AUXILLI
  • 8.54. AUXILIARY CONTROL VALVE 6 SEC
  • 8.55. PLUMBING INSTALLATION AUXILIA
  • 8.56. HOSE KIT AUXILIARY CIRCUIT
  • 8.57. HOSE KIT AUX CIRCUITS SAUER
  • 8.58. PLUMBING INSTALLATION MAINFRA
  • 8.59. HOSE KIT MAINFRAME HIGH PR
  • 8.60. PLUMBING INSTALLATION MAST HI
  • 8.61. HOSE KIT MAST HIGH PRESSURE P
  • 8.62. DIVERTER VALVE ASSEMBLY 2 POS
  • 8.63. PLUMBING INSTALLATION MAINFR
  • 8.64. MAST LOW PRESSURE PLUMBING INST
  • 8.65. FILTER INDICATOR INSTALLATION
  • 8.66. PRESSURE SWITCH W CONNECTOR
  • 8.67. PRESSURE SWITCH W CONNECTOR 1
  • 8.68. PRESSURE SWITCH W CONNECTOR 2
  • 8.69. HAMMER OIL TANK INSTALLATION
  • 8.70. HAMMER OIL TANK ASSEMBLY
  • 8.71. FILTER REGULATOR LUBRICATOR
  • 8.72. HOSE KIT HAMMER OIL TANK
  • 8.73. PLUMBING INSTALLATION WINCH
  • 8.74. PLUMBING INSTALLATION WINCH P
  • 8.75. HOSE KIT WINCH MAINFRAME
  • 8.76. PLUMBING INSTALLATION DUST CU
  • 8.77. HOSE KIT DUST CURTAIN LIFTERS
  • 8.78. HVAC HYDRAULIC PLUMBING
  • 8.79. HOSE KIT HVAC UNIT
  • 8.80. PLUMBING HVAC COOLANT
  • 9. Binder9
  • 9.1. SECTION 9 ELECTRICAL
  • 9.2. PLC ASSEMBLY
  • 9.3. ENCLOSURE MAIN J BOX
  • 9.4. BREAKER PANEL ASSEMBLY
  • 9.5. ENCLOSURE RAF J BOX
  • 9.6. LAF ENCLOSURE J BOX
  • 9.7. HYDRAULIC TANK ENCLOSURE J BO
  • 9.8. ENCLOSURE MAST J BOX
  • 9.9. INCLINOMETER J BOX ENCLOSURE
  • 9.10. BATTERY BOX INSTALLATION
  • 9.11. BATTERY BOX ASSEMBLY
  • 9.12. BATTERY ISOLATOR INSTALLATION
  • 9.13. BATTERY DISCONNECT BOX ASSEMBLY
  • 9.14. BATTERY DISCONNECT BOX MODIFICA
  • 9.15. ISOLATION CONTROL STATION
  • 9.16. REMOTE BATTERY CONNECT KIT CAT
  • 9.17. E STOP INSTALLATION
  • 9.18. MAST CLEARANCE LIGHT INSTALLATI
  • 9.19. REMOTE WINCH INSTALLATION
  • 9.20. HARNESS WINCH CONTROL PENDANT
  • 9.21. DRILL MONITOR SYSTEM PLC
  • 9.22. CAMERA SYSTEM INSTALLATION
  • 9.23. CABLE ASSEMBLY CAMERA
  • 9.24. HARNESS ASSEMBLY CAMERA
  • 9.25. WIRELESS COM SYSTEM INSTALLATIO
  • 9.26. DRILL LIGHTS INSTALLATION
  • 10. Bckcvr_C
  • 11. Blank Page
  • 12. Blank Page
  • 13. Blank Page
  • 14. Blank Page
  • 15. Blank Page
  • 16. Blank Page
  • 17. Blank Page
  • 18. Blank Page
  • 19. Blank Page
  • 20. Blank Page
  • 21. Blank Page
  • 22. Blank Page
  • 23. Blank Page
  • 24. Blank Page
  • 25. Blank Page
  • 26. Blank Page
  • 27. Blank Page
  • 28. Blank Page
  • 29. Blank Page
  • 30. Blank Page
  • 31. Blank Page
  • 32. Blank Page
  • 33. Blank Page
  • 34. Blank Page
  • 35. Blank Page
  • 36. Blank Page
  • 37. Blank Page
  • 38. Blank Page
  • 39. Blank Page
  • 40. Blank Page
  • 41. Blank Page
  • 42. Blank Page
  • 43. Blank Page
  • 44. Blank Page
  • 45. Blank Page
  • 46. Blank Page
  • 47. Blank Page
  • 48. Blank Page
  • 49. Blank Page
  • 50. Blank Page
  • 51. Blank Page
  • 52. Blank Page
  • 53. Blank Page
  • 54. Blank Page
  • 55. Blank Page
  • 56. Blank Page
  • 57. Blank Page
  • 58. Blank Page
  • 59. Blank Page
  • 60. Blank Page
  • 61. Blank Page
  • 62. Blank Page
  • 63. Blank Page
  • 64. Blank Page
  • 65. Blank Page
  • 66. Blank Page
  • 67. Blank Page
Rate this product

Related products
