Caterpillar NR16NH Parts Manual

$50.00

  • Type Of Manual: Parts Manual
  • Number of Pages: 626
  • Size: 13.3MB
  • Format: PDF
Category:

Product details

  • Model List:

    • NR16NH
  • 1. A BATTERY CHANGING DEV BATTERY WIDTH -310
  • 2. B SLEEVE
  • 3. G ASSEMBLY BATTERY BRACKET 620Ah
  • 4. K MAST UNIT FOR 2000/2500kg CAPASITY
  • 5. C LIFTING CARRIAGE FOR 1400/1600kg CAPASITY
  • 6. G ASSEMBLY BATTERY BRACKET 465Ah
  • 7. F DISPLAY UNIT
  • 8. D LIFTING CARRIAGE FOR 2000/2500kg CAPASITY
  • 9. P C LIFTING CARRIAGE
  • 10. L ASSEMBLY MAIN ASSEMBLY
  • 11. C BASE FOR 1600kg MODEL, STANDARD
  • 12. A DRIVE WHEEL VULKOLLAN
  • 13. A LOAD SUPPORT STANDARD/COMPACT CHASSIS
  • 14. B LIFTING FORK FOR 1400/1600kg CAPASITY,H.P.1150-100×40
  • 15. J MAST UNIT FOR 1400/1600kg CAPASITY
  • 16. E ACCESSORIES DISPLAY FORK CAMERA, L.H. 6301-7500
  • 17. D OPERATOR COMPARTMENT CAT
