BT SC Electric Counter Balanced Walkie Stacker Repair Manual 300376-000
BT SC Electric Counter Balanced Walkie Stacker Repair Manual 300376-000 - Image 2
BT SC Electric Counter Balanced Walkie Stacker Repair Manual 300376-000 - Image 3
BT SC Electric Counter Balanced Walkie Stacker Repair Manual 300376-000 - Image 4
BT SC Electric Counter Balanced Walkie Stacker Repair Manual 300376-000 - Image 5

BT SC Electric Counter Balanced Walkie Stacker Repair Manual 300376-000

$30.00

  • Type Of Manual: Repair Manual
  • Manual ID: 300376-000
  • : Service Manual PDF
  • Number of Pages: 134
  • Size: 6.4MB
  • Format: PDF
Category:

Product details

  • Model List:

    • SC Electric Counter Balanced Walkie Stacker
  • 1. Front Cover
  • 2. Interduction
  • 3. Table of Contents
  • 4. Alphabetized Index
  • 5. Acronym Definition
  • 6. General
  • 6.1. Parts Ordering Instructions
  • 6.2. Field Modifications
  • 6.3. Operating Practices
  • 6.4. Warnings
  • 6.5. Component Identification
  • 7. Planned Maintenance Procedures
  • 7.1. Grease and Lub Points
  • 7.2. Fill Points
  • 7.3. Planned Maintenance Procedures
  • 7.4. Inspection Form
  • 7.5. PM Schedule and Procedure
  • 7.6. PM Schedule Chart
  • 8. Specifications
  • 8.1. General Hydraulic Schematic
  • 8.2. Hydraulic Schematic Symbols
  • 8.3. General SCR EV100 Electrical Schematic
  • 8.4. Electrical Schematic Symbols
  • 8.5. Component Data
  • 9. Adjustments
  • 9.1. Mechanical Brake
  • 9.2. Interlock Switch
  • 9.3. Lidt Chain
  • 9.4. Gear Case Guide Ring
  • 9.5. Transmission Rollers
  • 9.6. Backlash on Transmission
  • 9.7. Control Valve Switches
  • 10. Specal Tools
  • 11. Frame
  • 11.1. Load Wheels
  • 11.2. Drive Wheel
  • 12. Controls
  • 12.1. Handle and Transmission
  • 12.2. Directional Control Switch
  • 13. Transmission
  • 13.1. Remove Handle and Transmission
  • 13.2. Transmission
  • 14. Electrical
  • 14.1. General
  • 14.2. General SCR EV100 Electrical Schematic
  • 14.3. EV100 SCR Control
  • 14.4. EV100 Operation and Maintenance
  • 14.5. Trouble-Shooting Instructions
  • 14.6. Checking Components
  • 14.7. Replacement of EV100 Components
  • 14.8. High Speed Contactor
  • 14.9. Forward and Rearward Contactor
  • 14.10. Drive Motor
  • 14.11. Prestolite Motor Service Instructions
  • 15. Hydraulic
  • 15.1. Lift Pump
  • 15.2. Lift Control Valve
  • 15.3. Tilt Cylinder
  • 15.4. Lift Cylinder
  • 15.5. SideShifter Cylinder
  • 15.6. Hose Reel
  • 15.7. Dual Elbow Swivels
  • 16. Mast
  • 16.1. Two Stage Mast
  • 16.2. Three Stage Mast
  • 16.3. Sideshifter
  • 17. Troubleshooting
  • 17.1. Index for Resistor Trucks
  • 17.2. Index for EV100 SCR Trucks
  • 18. Back Cover
