mt645d mt655d mt665d mt675d mt685d bleeding the pneumatic brake

Challenger MT645D, MT655D, MT665D, MT675D, MT685D Tractor Workshop Manual

Challenger MT645D, MT655D, MT665D, MT675D, MT685D Tractor Workshop Manual

$47.00

Challenger MT645D, MT655D, MT665D, MT675D, MT685D Tractor Workshop Manual : 2950 Pages
Technician Service Book MT600C (Schematics and Electronics) : 320 Pages
Operators Manual MT645D, MT655D, MT665D, MT675D, MT685D: 330 Pages
Spicer Dana Axle Service Manual: 625 Pages
Parts Catalog MT600C : 435 Pages
Engine Manual AGCO SISU: 113 Pages

Category: Challenger

AGCO (36)
- AGCO (36)
All Product (4408)
- CAT (4408)
  - Articulated Dump Truck (101)
    - Articulated Dump Truck (101)
    - CAT (101)
  - Asphalt (121)
    - Asphalt (121)
    - CAT (121)
  - Compactor (68)
    - CAT (68)
    - Compactor (68)
  - Dozer (761)
    - Articulated Dump Truck (1)
    - CAT (761)
    - Dozer (758)
    - Engine (2)
  - Engine (922)
    - CAT (922)
    - Engine (922)
  - Excavator (1252)
    - CAT (1252)
    - Excavator (1252)
  - Forklift (59)
    - CAT (59)
    - Forklift (59)
  - Loader (654)
    - CAT (654)
    - Loader (654)
      - CAT (0)
      - Loader (0)
  - Motor Grader (228)
    - CAT (228)
    - Motor Grader (228)
  - Scraper (90)
    - CAT (90)
    - Scraper (90)
  - Skidder (17)
    - CAT (17)
    - Skidder (10)
    - Skidsteer (7)
  - Skidsteer (106)
    - CAT (106)
    - Skidsteer (106)
  - Telehandler (29)
    - CAT (29)
    - Telehandler (29)
Ammann (22)
- Ammann (22)
BT (25)
- BT (25)
Cameco (3)
- Cameco (3)
Challenger (45)
- Challenger (45)
Claas (2)
- Claas (2)
Clark (50)
- Clark (50)
Cub Cadet (29)
- Cub Cadet (29)
Fendt (39)
- Fendt (39)
Hino (27)
- Hino (27)
Hyster (50)
- Hyster (50)
Kawasaki (50)
- Kawasaki (50)
Linde (31)
- Linde (31)
Linkbelt (1)
- Linkbelt (1)
Mack (10)
- Mack (10)
Manitou (16)
- Manitou (16)
Mitsubishi (50)
- Mitsubishi (50)
OM Pimespo (50)
- OM Pimespo (50)
Perkins Engines (11)
- Perkins Engines (11)
Sany (17)
- Sany (17)
Scania (1)
- Scania (1)
Sennebogen (26)
- Sennebogen (26)
Skoda (24)
- Skoda (24)
STILL GmbH (50)
- STILL GmbH (50)
Sumitomo (17)
- Sumitomo (17)
Toro (48)
- Toro (48)
Toyota Forklift (50)
- Toyota Forklift (50)
Valtra (50)
- Valtra (50)
Yale (50)
- Yale (50)
Yanmar (22)
- Yanmar (22)

Description

Challenger MT645D, MT655D, MT665D, MT675D, MT685D Tractor Repair Workshop Manual

Manual for: AGCO Challenger MT400D Series Tractor
Format: PDF
Book Number: 436278m3
English
Issued June 2011

Challenger MT400D Series Manual TABLE OF CONTENTS

Introduction
Separation of assemblies
Engine
Clutch
Gearbox
Rear Axle
Power Take off
Front Axle
Hydraulics
Electricity
Electronics
Cab
Accessories
Services Tools

MT645D, MT655D, MT665D, MT675D, MT685D Manual Extract

Bleeding the pneumatic brake
1. The hydraulic section of the pneumatic tractor brakes is bled through bleed plugs (1) located at the rear right-hand side of the tractor.
2. Start the engine.
3. Connect a flexible pipe (preferably transparent) to the bleed plugs (1) and then connect them to the hydraulic tank.
4. Open the trailer brake bleed plug (1).
5. Press moderately on the coupled brake pedals, with pedal travel of approximately 20 mm (0.8 in).

NOTE: Never press the pedals down more than 25 mm (1.0 in) when the bleed plugs are open. A jet of pressurised oil will spurt out of the bleed plugs.
6. Let the air bleed out at the plugs.
7. Close the plug again when the fluid coming out no longer shows any trace of foam or air bubbles. Release the pedals.
8. Bleed the main brakes of the tractor see 1A16, §2.2, page 497.
9. Check the oil levels in the auxiliary hydraulics and gearbox.
