Description

Kawasaki 70ZV Wheel Loader Service Manual

Machinery Type: 70ZV or 70Z5 Wheel Loader
Language English
Format: PDF

Kawasaki 70ZV Wheel Loader Repair Service Manual – 929 Pages
Kawasaki 70ZV Wheel Loader Parts Catalog Manual – 616 Pages

Manual Details

This manual contains guidelines on repair and maintenance work for the 70ZV Loader. All explanations, drawings and photographs are current at the time of going to press.

Repair and maintenance work should be carried out systematically and logically after thoroughly reading and understanding this manual to ensure that the shovel loader gives reliable, long-term service.

The manual is structured as follows to make it easy to use

SHOP SERVICE MANUAL CONTENT:

• 01 GENERAL OUTLINE
• 10 FUNCTIONS AND CONSTRUCTION
• 20 INSPECTION AND ADJUSTMENT
• 30 DISASSEMBLY AND ASSEMBLY
• 40 MAINTENANCE STANDARDS


The most important maintenance operations are those related to safety. The points that  have special significance from the safety point-of-view are indicated with a A mark in this manual.

Manual Extract: Accumulator circuit pressure measurement and adjusting

Accumulator line pressure is regulated by the unloader valve. However, the reducing valve also may affect brake manifold pressure or accumulator pressure, as it is installed between the unloader valve and brake manifold.
Measure pressure at the ACF ports to determine the manifold pressure when there is a brake pressure problem.
