BT CSX Electric Counter Balanced Stacker Truck Parts Manual 304954-000

$30.00

Type Of Manual: Parts Manual
Manual ID: 304954-000
: Parts Manual PDF
Number of Pages: 228
Size: 4.2MB
Format: PDF

Category: BT Parts Manual PDF

Model List:
- CSX Electric Counter Balanced Stacker Truck

1. F r o n t C over
2. Parts Ordering Instructions
3. General Information
4. Chassis
4.1. Frame / Chassis
4.2. Inspection covers (Shields guards)
4.3. Inspection covers (EE electrical box)
4.4. Counter balance weight
4.5. Battery compartment parts (7 in. 178 mm battery)
4.6. Battery compartment parts (9 in. 229 mm battery)
4.7. Battery compartment parts (13.3 in. 338 mm battery)
4.8. Drivers controls (One spool valve handle)
4.9. Drivers controls (Two spool valve handle)
4.10. Drivers controls (Speed and direction)
4.11. Driver protection (Reverser)
4.12. Signs, warnings
5. Motors
5.1. Pump motor
5.2. Amp system drive motor Serial Number 27108001 – UP
5.3. AMP system drive motor
6. Transmission / Drive Gear
6.1. Mechanical drive gear unit
7. Brake / Wheel System
7.1. Amp system parking brake system
7.2. Amp system parking brake system
7.3. Brake drum/disc assembly
7.4. Drive wheel
7.5. Support / swivel wheel
7.6. Load wheels
7.7. Caster assembly
8. Steering System
8.1. Steering arm / wheel (Tiler arm) Serial Number 27324000 – UP
8.2. Steering arm / wheel (Control head assembly)
8.3. Steering / radial bearing
9. Electrical System
9.1. Horn
9.2. Static strap
9.3. Battery connector
9.4. Amp system line contactor
9.5. Amp system line contactor
9.6. Amp system EE line contactor
9.7. Voltage / battery indicator
9.8. Hourmeter / speedometer
9.9. Start / stop switch
9.10. Speed controls
9.11. Control cables / harnesses
9.12. Amp system motor power cables
9.13. Amp system motor power cables
9.14. Amp system transistor panel
9.15. Amp system transistor panel
9.16. Micro switches
9.17. Control cables, harness
9.18. Pump contactor
9.19. Control circuit breaker
9.20. Power circuit breaker
10. Hydraulic System
10.1. Hydraulic pump (Model DM-1005)
10.2. Hydraulic pump (Model DM-1006)
10.3. Hydraulic tank
10.4. One spool valve hydraulic lines
10.5. Two spool valve hydraulic lines
10.6. CSX10 Two stage mast lines Serial Number 28163001 – UP
10.7. Two stage mast lines Serial Number 28163001 – UP
10.8. Two stage mast lines
10.9. Two stage full freelift lines
10.10. Three stage mast lines
10.11. Control valve (One spool control valve)
10.12. Control valve (Two spool control valve)
10.13. Pressure / flow control valve
10.14. Control valve (Manifold assembly)
10.15. Two stage mast lift cylinder Serial Number 28163001 – UP
10.16. Two stage mast lift cylinder
10.17. Two stage full freelift staging cylinder
10.18. Three stage mast staging cylinder
10.19. Two stage full freelift, freelift cylinder
10.20. Three stage mast freelift cylinder
11. Operating Function – Lifting Device
11.1. Mast pivot
11.2. Two stage mast Serial Number 28163001 – UP
11.3. Two stage mast
11.4. Two stage full freelift mast
11.5. Three stage mast
11.6. Two stage mast lifting gear
11.7. Two stage full freelift mast liftting gear
11.8. Two / three stage mast lifting gear
11.9. Sideshifter assembly Serial Number 28077002 – UP
11.10. Tilt cylinder
11.11. Fork assembly
11.12. Two stage mast fork carriage unit
11.13. Two stage mast fork carriage unit
11.14. Two stage full freelift mast fork carriage unit
11.15. Three stage mast fork carriage unit
12. Peripheral / Installation Equipment
13. Options / Attachments
13.1. Attachments (Supply line to mast)
13.2. Attachments (Two stage mast lines)
13.3. Attachments (Three stage mast lines)
13.4. Warning lights / alarm
13.5. Positioning equipment
13.6. Load backrest
13.7. Electrical heater
14. Tools
14.1. Electrical controllers (Handset)
14.2. Special tools and lubrications
15. Numerical Index
15.1. CSX Electical Truck Numerical Index
16. Back Cover
