BT RTX35, RTX45 Electric Stand-Up Rider Truck Parts Manual 310427-001

BT RTX35, RTX45 Electric Stand-Up Rider Truck Parts Manual 310427-001 - Image 2

BT RTX35, RTX45 Electric Stand-Up Rider Truck Parts Manual 310427-001 - Image 3

BT RTX35, RTX45 Electric Stand-Up Rider Truck Parts Manual 310427-001 - Image 4

BT RTX35, RTX45 Electric Stand-Up Rider Truck Parts Manual 310427-001 - Image 5

bt rtx35 rtx45 electric stand up rider truck parts manual 310427 001 2

bt rtx35 rtx45 electric stand up rider truck parts manual 310427 001 3

BT RTX35, RTX45 Electric Stand-Up Rider Truck Parts Manual 310427-001

$30.00

Type Of Manual: Parts Manual
Manual ID: 310427-001
: Parts Manual PDF
Number of Pages: 282
Size: 16.3MB
Format: PDF

Category: BT Parts Manual PDF

Model List:
- RTX35, RTX45 Electric Stand-Up Rider Truck

1. F r o n t C o v e r
2. Parts Ordering Instructions
3. General Information
4. Chassis
4.1. Inspection covers
4.2. Inspection covers (EE Contactor Enclosure)
4.3. Inspection covers (EE A5 Card Enclosure)
4.4. Battery compartment parts
4.5. Motor mounting points
4.6. Cushions
4.7. Driver controls
4.8. Driver handle assembly
4.9. RTX35 Brake pedal without brake on caster
4.10. RTX45 Brake pedal with brake on caster
4.11. Internal fittings
4.12. Overhead guard
4.13. Finger / toe guards
4.14. Signs, warnings
5. Motors
5.1. Steering motor
5.2. Fan motor
5.3. RTX35 Pump motor
5.4. RTX45 Pump motor
5.5. Drive motor, 24 Volt
5.6. Drive motor, 36 Volt
6. Transmission / Drive Gear
6.1. Mechanical drive gear unit
7. Brake / Wheel System
7.1. RTX45 Brake drum/disc assembly
7.2. Electromagnetic brake
7.3. Drive wheel
7.4. RTX35 Non-Braking caster wheel
7.5. RTX35 Non-Braking caster assembly
7.6. RTX45 Braking caster wheel
7.7. RTX45 Braking caster assembly
7.8. Closed toe load wheel (4 in. x 3 in.)
7.9. Open toe load wheel (4 in. x 3 in.)
7.10. Closed toe load wheel (5 in. x 4 in.)
7.11. Open toe load wheel (5 in. x 4 in.)
7.12. Load wheel (5 in. x 3 in.)
7.13. Load wheel (10.5 in. x 3.5 in.)
7.14. Caster wheel
8. Steering System
8.1. Steering arm / wheel / lever
8.2. Steering bearing, radial bearing
8.3. Steering Unit
9. Electrical System
9.1. Lights
9.2. Horn
9.3. Static strap
9.4. RTX45 Lift bypass contactor
9.5. Battery cut out contactor / plug
9.6. Battery connector
9.7. Instrument panel
9.8. Indicator, lift height
9.9. Start / stop switch
9.10. Speed cut-back controls
9.11. Relays, electrical modules
9.12. Control cable / harness
9.13. Motor cables / resistors
9.14. Direction contactors
9.15. Transistor panel (drive)
9.16. Transistor panel (lift)
9.17. Micro switches (lights, fan)
9.18. PCBs logic card / box Serial Number 31155001 – UP
9.19. Lift/lowering/reach movement probes/sensors
9.20. Positioning probes/switches/sensors
10. Hydraulic System
10.1. RTX45 Auxiliary Hydraulic tank
10.2. Hydraulic tank
10.3. Hoses, pipes, connections, mounting points
10.4. RTX35 Three stage mast lines
10.5. RTX45 Three stage mast lines
10.6. RTX35 Three stage mast hoses
10.7. RTX45 Three stage mast hoses
10.8. RTX35 Reach supply lines
10.9. RTX45 Reach supply lines
10.10. RTX35 Tilt cylinder hoses
10.11. RTX45 Tilt cylinder hoses
10.12. RTX35 Sideshifter cylinder hoses
10.13. RTX45 Standard reach sideshifter cylinder hoses
10.14. RTX35 Reach cylinders hoses
10.15. RTX45 Reach cylinders hoses
10.16. RTX35 Filter assembly
10.17. RTX45 Filter assembly
10.18. RTX35 Hydraulic pump
10.19. RTX45 Hydraulic pump
10.20. Control valve assembly (Lift/Auxiliary functions)
10.21. RTX35 Control valve with No Sideshifter
10.22. RTX35 Control valve With Sideshifter
10.23. RTX45 Solenoid valve assembly
10.24. RTX45 Solenoid valve assembly
10.25. RTX35 Three stage mast staging cylinder
10.26. RTX45 Three stage mast staging cylinder
10.27. RTX35 Three stage mast freelift cylinder
10.28. RTX45 Three stage mast freelift cylinder
10.29. RTX35 Reach cylinder assembly
10.30. RTX45 Reach cylinder assembly
10.31. RTX35 Tilt Cylinder assembly
10.32. RTX45 Tilt Cylinder assembly
11. Operating Function – Lifting Device
11.1. Mast pivot
11.2. RTX35 Three stage mast Serial Number 31339001 -UP
11.3. RTX45 Three stage mast
11.4. RTX35 Lifting gear (Three stage mast)
11.5. RTX45 Lifting gear (Three stage mast)
11.6. Sideshifter assembly
11.7. RTX35 Reach assembly Serial Number 31333001 – UP
11.8. RTX45 Reach assembly
11.9. Fork assembly
12. Peripheral / Installation Equipment
12.1. Access, safety equipment (Fire extinguisher)
13. Options / Attachments
13.1. RTX35 Load indicator
13.2. RTX45 Load indicator
13.3. Load indicator (Magnet and switch)
13.4. Extra lights
13.5. Warning lights / alarm
13.6. Load backrest
13.7. Electrical heater, part 1
13.8. Electrical heater, part 2
14. Tools
14.1. Special tools and lubrications
15. Alphabetical/ Numerical Index
15.1. Alphabetical Index
15.2. Numerical Index
16. Back Cover
